    • Lenovo ThinkCentre M90a Gen 6 24 inch - Intel Core Ultra 5 225 Processor - Windows 11 Home 64 - 8 GB DDR5-5600MT/s - 256 GB SSD - 13ATCTO1WWHK1

    Lenovo

    Request A Quote

    Write a Review
    SKU:
    HS-LEN-13ATCTO1WWHK1
    Condition:
    New
    Availability:
    Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |
    MPN:
    13ATCTO1WWHK1
    Note:
    Images may not be exact, please check specifications.
    Required A Volume Purchase:
    Contact us for a volume pricing | volumeorders@hssl.us

    Product Description

    Lenovo ThinkCentre M90a Gen 6 24 inch - Intel Core Ultra 5 225 Processor - Windows 11 Home 64 - 8 GB DDR5-5600MT/s - 256 GB SSD - 13ATCTO1WWHK1

    Key Details
    • Intel Core Ultra 5 225 Processor (E-cores up to 4.40 GHz P-cores up to 4.90 GHz)
    • Windows 11 Home 64
    • Integrated Graphics
    • 8 GB DDR5-5600MT/s (SODIMM)
    • 256 GB SSD M.2 2280 PCIe Gen4 TLC Opal
    • 23.8″ FHD (1920 x 1080), 250nit, antiglare
    • No Mouse
    • No Keyboard
    • Integrated Ethernet
    • 1 Year On-site
    • 23.8" FHD (1920 x 1080), IPS, Anti-Glare, Non-Touch, 99%sRGB, 250 nits, 120Hz, 180W 90% Power Supply

    Your All-in-One Solution for Smarter, Safer Work

    Boost your productivity with the 23.8″ Lenovo ThinkCentre M90a Gen 6 all-in-one PC. Intel Core Ultra processors and Intel AI Boost optimize system performance. The Lenovo AI Turbo Engine combined with the industry-first discrete neural processing unit (dNPU) enhance audio, video, and security capabilities to elevate efficiency.

    Audiovisual Brilliance for Every Moment

    Enjoy stunning visuals on the 23.8” AIO display with narrow bezels for an expansive viewing experience. Enjoy rich soundscapes by Dolby Atmos, while integrated Intel graphics and optional NVIDIA GeForce RTX graphics ensure flawless visuals with AI efficiency and power. Plus, TÜV Eyesafe and TÜV Low Blue Light technology help reduce eye strain.

    One Device, Endless Efficiency

    The M90a Gen 6 AIO PC boasts flexible port options, including Thunderbolt 4 with Thunderbolt Share for fast data transfers, and high-speed Wi-Fi for stable connectivity. Effortlessly link to monitors, smartphones, or laptops for PC-to-PC access, sharing screens, keyboards, or storage. With everything synchronized, productivity is seamless.

    Your Data Safe, Your Tasks Unstoppable

    Enjoy ultimate peace of mind with the M90a Gen 6 all-in-one PC. ThinkShield’s advanced security suite offers robust protection via a discrete Trusted Platform Module (dTPM) and smart user recognition. Plus, human presence detection with radar sensor safeguards sensitive data and Intel vPro ensures multilayer security for comprehensive protection.



    Tech Specs


    Performance
    Processor

    Up to Intel Core Ultra 9 on Intel vPro platform
    Operating System

    • Windows 11 Pro — Lenovo recommends Windows 11 Pro for business

    • Windows 11 Home

    • Windows 11 Home Single Language
    Neural Processing Unit (NPU)

    • Up to 13 trillion operations per second (TOPS) AI performance with Intel

    • Optional: Discrete M.2 NPU Card (Kinara Ara-2) with up to 30 TOPS AI performance
    Graphics

    • Intel integrated graphics with up to 8 TOPS

    • Optional: NVIDIA GeForce RTX 4050 with up to 194 TOPS
    Memory

    Up to 64GB DDR5
    Storage

    • 3 x M.2 SSD, up to 6TB

    • Optional: external module optical disc drive (ODD)
    Audio

    • 2 x 3W speakers

    • Dolby Atmos

    • Dual mics

    • Intel Gaussian & Neural Accelerator (GNA) – for AI-based noise cancelation
    Camera

    • 5M RGB & infrared (IR) with human presence detection & webcam privacy shutter (tiltable & rotatable)

    • 5M RGB & infrared (IR) with webcam privacy shutter (tiltable & rotatable)

    • 5M RGB with webcam privacy shutter (fixed angle)
    Internal Power Supply Unit

    • 230W (optional graphics)

    • 180W (UMA)


    Connectivity
    Ports/Slots

    Side:



    • USB-C (Thunderbolt 4, USB 40Gbps) with power delivery & DisplayPort 2.1

    • USB-A (USB 10Gbps)

    • USB-C (USB 10Gbps)

    • Optional: 3-in-1 card reader

    • Headphone / mic combo



    Rear:



    • 2 x USB-A (USB 5Gbps), one always on

    • 2 x USB-A (USB 10Gbps)

    • DisplayPort 1.4 out

    • Ethernet (RJ45)

    • HDMI 2.1 out (supports resolution up to 4K@60Hz) & HDMI 1.4 in (supports resolution up to AIO panel resolution 2560 x 1440@120Hz) combo

    • Optional: Serial port



    USB port transfer speeds are approximate and depend on many factors, such as processing capability of host/peripheral devices, file attributes, system configuration and operating environments; actual speeds will vary and may be less than expected.
    Wireless

    • Realtek Wi-Fi 7 (2x2 AX) with Bluetooth 5.4

    • Wi-Fi 6E (2x2 AX) with Bluetooth 5.3

    • Wi-Fi 6 (2x2 AX) with Bluetooth 5.2



    * 6GHz WiFi 6E operation is dependent on the support of the operating system, routers/APs/gateways that support WiFi 6E, along with the regional regulatory certifications and spectrum allocation.


    Design
    Display



    • 23.8″ FHD (1920 x 1080), 4 side near-edgeless, 250nit, 99% sRGB, 120Hz, 1500:1 contrast ratio, 14ms response time, 16.7M color support, in-plane switching, antiglare, TÜV  Flicker Free, TÜV Eyesafe, TÜV Low Blue Light, IP55 (front face only), touchscreen

    • 23.8″ FHD (1920 x 1080), 4 side near-edgeless, 250nit, 99% sRGB, 120Hz, 1500:1 contrast ratio, 14ms response time, 16.7M color support, in-plane switching, antiglare, TÜV Flicker Free, TÜV Eyesafe, TÜV Low Blue Light, IP54 (front face only)


    Dimensions (H x W x D)

    • Without stand: Starting from 49.55mm x 539.6mm x 340.2mm / 1.95″ x 21.24″ x 13.39″

    • Optional: With Full Function Monitor Stand: Starting from 221.21mm x 539.6mm x 393.01mm / 8.75″ x 21.24″ x 15.47″

    • Optional: With Ultra-Flex V Stand: Starting from 224.10mm x 539.6mm x 333.45mm / 8.82″ x 21.24″ x 13.13″

    • Optional: With Tilt-Only Stand: Starting from 213.14mm x 539.6mm x 442mm / 8.39″ x 21.24″ x 17.4″
    Weight

    • Without stand: Starting from 6kg / 13.23lbs

    • Optional: With Ultra-Flex V Stand: Starting from 8.04kg / 17.73lbs

    • Optional: With Full-function Stand: Starting from 8.96kg / 19.75lbs

    • Optional: With Tilt-Only Stand: Starting from 8kg / 17.64lbs
    Display Stand Functionality

    Full Function Monitor Stand:



    • Tilt: -5 to 20 degrees

    • Lift: 150mm

    • Pivot: 90 degrees

    • Swivel: 90 degrees, 45 degrees left & right



    Optional: Ultra-Flex V Stand



    • Tilt: -5 to 70 degrees

    • Lift: 70 ± 2 degrees with vertical lift range of 102mm





    Optional: Tilt only Stand



    • Tilt: -5 to 25 degrees
    Mounting Options

    • Without stand

    • Optional: Full-function Monitor Stand

    • Optional: Ultra-Flex V Stand

    • Optional: Tilt-Only Stand
    Color

    Raven Black


    Sustainability
    Material



    • 95% recycled post-consumer content (PCC) acrylonitrile butadiene styrene (ABS) plastic used in wired keyboard & mouse

    • 90% paper pulp used in package cushion

    • 85% recycled PCC ABS used in partial of plastic parts

    • 30% ocean-bound plastic (OBP) used in device bag

    • Forest Stewardship Council (FSC)-certified carton


    Certifications / Registries

    • ENERGY STAR 9.0

    • Forest Stewardship Council (FSC)

    • Healthcare compliance (Partial of IEC 60601-1 / IEC 60601-1-2)

    • Intelligent Cooling Engine (ICE) 7.0

    • IP55*

    • IP54*

    • MIL-STD-810H

    • RoHS

    • SGS** High Performance L1

    • TCO 10.0

    • TCO Edge

    • TÜV Eyesafe

    • TÜV Flicker Free

    • TÜV Low Blue Light

    • TÜV Ultra Low Noise

    • UL Anti-Dust



    *Available on select model configurations, front face only

    **(SGS Ultra-Low Noise Certified with level 1 high performance)


    Other information
    ThinkShield Security



    • Human Presence Detection (HPD) 2.0

    • Error correction (EC) self-healing (Level 2)

    • BIOS-based Smart USB Protection

    • Intel vPro Enterprise

    • Discrete Trusted Platform Module (dTPM) 2.0

    • Kensington Security Slot

    • Optional: Intrusion switch

    • Windows Hello with facial recognition (requires optional IR camera)

    • Mic-mute button & LED indicator


    Preloaded Software

    • Lenovo Commercial Vantage

    • Lenovo Device Manager

    • Lenovo Smart Meeting

    • Microsoft Team

    • Office 365 (trial)
    What’s in the Box

    • Lenovo ThinkCentre M90a Gen 6 (24” Intel) AIO

    • Quick Start Guide

    Other Details

    (Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request page
