Product Description
SIIG HDMI 2.0 KVM Over Cat6 Extender with Loopout & S/PDIF - 1 Computer - 1 Local User - 229.66 ft Range - 4K - 2 x Network RJ-45 - 3 x USB - 3 x HDMI - 120 V AC, 240 V AC Input Voltage
Features
- Extends and transmits 4K@60Hz HDMI 2.0 video/audio and USB 2.0 signals up to 230ft (70m) through a Cat6/6a/7 network cable with nearly with zero latency
- Supports USB 2.0 extension to the receiver, allowing you to connect a wired/wireless keyboard and mouse to control your computer remotely
- Supports digital audio extraction through the receiver's S/PDIF port, with PCM 2ch, Dolby, DTS 5.1
- The transmitter's HDMI loop-out allows for local monitoring of the extended display
- The transmitter can work as an HDMI splitter with the additional HDMI output design, and allows screen mirroring to another display device
- Lightning protection, surge protection, ESD protection
- Plug and play, no driver installation required
- High quality metal housing with ventilation panels improve heat dissipation and ensure system stability during long hours of operation
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
Package Contents
- HDMI 2.0 KVM Over Cat6 Extender with Loopout & S/PDIF
- 2 x Power Adapter
- USB 2.0 Type-A to Type-A cable
- Mounting Ears & Screw kit
- User Manual
Product Type KVM Extender
Input Voltage 120 V AC
Input Voltage 240 V AC
Manufacturer Part Number CE-H26Y11-S1
Limited Warranty 2 Year
Connectivity Technology Wired
Manufacturer SIIG, Inc
Product Name HDMI 2.0 KVM Over Cat6 Extender with Loopout & S/PDIF
Brand Name SIIG
Input Voltage Range 100V AC to 240V AC
Country of Origin China
Environmentally Friendly Yes
Environmental Certification RoHS
Graphic Mode 4K
Maximum Operating Distance 229.66 ft
USB Yes
HDMI Yes
Number of HDMI Ports 3
Number of Network (RJ-45) Ports 2
Network (RJ-45) Yes
Number of USB Ports 3
Number of Computers Supported 1
Number of Local Users Supported 1
Transmitter Height 0.98"
Transmitter Width 5.91"
Transmitter Depth 4.13"
Receiver Height 0.98"
Receiver Width 5.91"
Receiver Depth 4.13"
Transmitter Weight (Approximate) 8.80 oz
Receiver Weight (Approximate) 8.80 oz
Device Type KVM Extender
Note Images may not be exact, please check specifications.
