AsRock 4U2G-W790 4U Rackmount with 1, 80-PLUS Gold, 2000W ATX PSU - Single Socket E (LGA 4677), Supports Intel Xeon W-2400 And W-3400 Series Processors

Name: AsRock 4U2G-W790 4U Rackmount with 1, 80-PLUS Gold, 2000W ATX PSU - Single Socket E (LGA 4677), Supports Intel Xeon W-2400 And W-3400 Series Processors
Brand: Asrock Rack
SKU: HS-ASR-4U2G-W790
Availability: OutOfStock

Asrock Rack

Request A Quote

Write a Review

SKU:: HS-ASR-4U2G-W790
Condition:: New
Availability:: Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |
MPN:: 4U4G-GENOAX
Form Factor:: 4U Rackmount
Dimensions:: 596 x 430.4 x 174.8 mm (23.5'' x 16.9'' x 6.9'')
Support MB:: W790D8UD-1L1N2T/BCM
Buttons:: Power w/ LED, ID w/ LED, System Reset, NMI
LEDs:: LAN Activity, HDD Activity, System Event
I/O Ports:: 2 Type-A (USB3.2 Gen1)
Internal Side:: 4 fixed SATA drive bays
Internal Side:: 1 M-key (PCIe4.0 x4), supports 2280 form factor [PCH]
Type:: 1 ATX PSU
Output Watts:: 1100W, 1300W @ 100-240Vac input / 1500W, 1650W @ 115-240Vac input / 2000W @ 200-240Vac input
Efficiency:: 80-PLUS Gold
AC Input:: AC 100-240V/15-6A; AC 115-240V/15-8A ; AC 200-240V/12A, 50-60Hz
Fan:: 4 PWM fixed 80x38 mm fans
CPU:: Supports Intel® Xeon® W-2400 and W-3400 series processors
Socket:: Single Socket E (LGA 4677)
Chipset:: Intel W790
Supported DIMM Quantity:: 8 DIMM slots (2DPC)
Supported Type:: Supports DDR5 288-pin RDIMM, RDIMM-3DS
Max. Capacity per DIMM:: RDIMM: 64GB
Max. Capacity per DIMM:: RDIMM-3DS: 2H- 128 GB/ 4H- 256 GB
Max. DIMM Frequency:: 4400MT/s (2DPC) / 4800MT/s (1DPC)
Voltage:: 1.1V
BMC Controller:: ASPEED AST2600: iKVM, vMedia support
IPMI Dedicated GLAN:: 1 RJ45 Dedicated IPMI LAN port by Realtek RTL8211F
Controller:: ASPEED AST2600: 1 DB15 (VGA)
UID Button/LED:: 1 UID button w/ LED
VGA Port:: 1 DB15 (VGA)
Serial Port:: 1 DB9 (COM)
USB 3.2 Gen1 Port:: 2 Type-A (USB3.2 Gen1)
RJ45:: 2 RJ45(10GbE), 1 RJ45(2.5GbE), 1 RJ45(1GbE), 1 dedicated IPMI
BIOS Type:: AMI 256Mb SPI Flash ROM
BIOS Features:: Plug and Play, ACPI 5.0 and above compliance wake up events, SMBIOS 2.3 and above, ASRock Rack Instant Flash
Note:: Images may not be exact, please check specifications.
Required A Volume Purchase:: Contact us for a special pricing for Volume orders. sales@hssl.us

Overview
Other Details

Product Description

AsRock 4U2G-W790 4U Rackmount with 1, 80-PLUS Gold, 2000W ATX PSU - Single Socket E (LGA 4677), Supports Intel Xeon W-2400 And W-3400 Series Processors

FEATURES

4U Rackmount with 1, 80-PLUS Gold, 2000W ATX PSU
Single Socket E (LGA 4677), supports Intel^® Xeon^® W-2400 and W-3400 series processors
8 DIMM slots (2DPC), supports DDR5 RDIMM, RDIMM-3DS
4 fixed SATA drive bays
2 FHFL dual-slot PCIe5.0 x16 or 4 FHFL single-slot PCIe5.0 x16
Supports 1 M.2 (PCIe4.0 x4)
2 RJ45 (10GbE) by Broadcom BCM57416
1 RJ45 (2.5GbE) by Intel^® i226
1 RJ45 (1GbE) by Intel^® i210
Remote management (IPMI)

PRINT DATASHEET

Other Details

(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request page

Product Videos

Custom Field

MPN 4U4G-GENOAX

Form Factor 4U Rackmount

Dimensions 596 x 430.4 x 174.8 mm (23.5'' x 16.9'' x 6.9'')

Support MB W790D8UD-1L1N2T/BCM

Buttons Power w/ LED, ID w/ LED, System Reset, NMI

LEDs LAN Activity, HDD Activity, System Event

I/O Ports 2 Type-A (USB3.2 Gen1)

Internal Side 4 fixed SATA drive bays

Internal Side 1 M-key (PCIe4.0 x4), supports 2280 form factor [PCH]

Type 1 ATX PSU

Output Watts 1100W, 1300W @ 100-240Vac input / 1500W, 1650W @ 115-240Vac input / 2000W @ 200-240Vac input

Efficiency 80-PLUS Gold

AC Input AC 100-240V/15-6A; AC 115-240V/15-8A ; AC 200-240V/12A, 50-60Hz

Fan 4 PWM fixed 80x38 mm fans

CPU Supports Intel® Xeon® W-2400 and W-3400 series processors

Socket Single Socket E (LGA 4677)

Chipset Intel W790

Supported DIMM Quantity 8 DIMM slots (2DPC)

Supported Type Supports DDR5 288-pin RDIMM, RDIMM-3DS

Max. Capacity per DIMM RDIMM: 64GB

Max. Capacity per DIMM RDIMM-3DS: 2H- 128 GB/ 4H- 256 GB

Max. DIMM Frequency 4400MT/s (2DPC) / 4800MT/s (1DPC)

Voltage 1.1V

BMC Controller ASPEED AST2600: iKVM, vMedia support

IPMI Dedicated GLAN 1 RJ45 Dedicated IPMI LAN port by Realtek RTL8211F

Controller ASPEED AST2600: 1 DB15 (VGA)

UID Button/LED 1 UID button w/ LED

VGA Port 1 DB15 (VGA)

Serial Port 1 DB9 (COM)

USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1)

RJ45 2 RJ45(10GbE), 1 RJ45(2.5GbE), 1 RJ45(1GbE), 1 dedicated IPMI

BIOS Type AMI 256Mb SPI Flash ROM

BIOS Features Plug and Play, ACPI 5.0 and above compliance wake up events, SMBIOS 2.3 and above, ASRock Rack Instant Flash

Note Images may not be exact, please check specifications.

Required A Volume Purchase Contact us for a special pricing for Volume orders. sales@hssl.us
