Product Details
| Physical Ports | |
| I/O Ports | - 48 x SFP28 supporting 10/25GbE - 8 x QSFP28 supporting 40/100GbE, or 4x10/4x25/2x50GbE with breakout cables |
| Management | - 1 x RJ45 10/100/1000BASE-T |
| Console | - 1 x RJ45 RS232 |
| USB | - 1 x USB 2.0 Type A |
| Switch ASIC | |
| - Marvell Falcon 98CX8512 | |
| Processor | |
| CPU | - Intel® Broadwell-DE® D-1517 |
| Memory | - Default 8GB DDR4 - Max 32GB DDR4 |
| Storage | - 16GB eMMC NAND FLASH - SSD module optional |
| BMC | |
| - AST2520 optional | |
| Performance and Scalability | |
| Switching Capacity | - 2T bps |
| Forwarding Rate | - 2.8 Bpps |
| Jumbo frames | - Yes |
| Packet Buffer Size | - 24 MB |
| Transmit Descriptors | - 192K |
| Bridge FDB Entries | - Up to 256K |
| Router IPv4 Host Entries | - Up to 256K |
| Router IPv6 Host Entries | - Up to 128K |
| Router LPM | - IPv4 - up to 512K unicast prefixes - IPv6 - up to 256K unicast 64-bit prefixes |
| TCAM Resources (Shared between TTI, IPCL and EPCL Classification Engines) | - 36K x 10B rules (18K x 10B per dual control pipe) |
| Virtual Ports (ePorts) | - 8K |
| Bridge Domains (eVLANs) | - Up to 8K |
| Multicast Physical Port Groups (VIDX) | - Up to 4K |
| Multicast Virtual Port Groups (eVIDX) | - 16K |
| Multicast Linked List (MLL) Entries | - 16K |
| Tunnel-Start/ARP Table | - Up to 192K ARP entries - Up to 48K Non-IPv6 Tunnel-Start entries - Up to 24K IPv6 Tunnel-Start entries |
| Router Next Hop Entries | - 24K |
| Router ECMP Groups | - 12K |
| ePort ECMP Groups | - 16K |
| Trunk ECMP Groups | - Up to 4K |
| L2 ECMP Table (Shared by ePort ECMP group and Trunk ECMP groups) | - 16K ECMP members - Each ECMP group may contain up to 4K EMCP members |
| Hardware OAM Flows | - 16K ECMP members - 4K OAM flows (1K OAM flows per control pipe) |
| Spanning Tree Groups | - Up to 4K |
| Power and Cooling | |
| Power Supply | - Hot-swappable 2 PSU, input range 100-240VAC, 650W, 1+1 redundancy |
| Power Consumption | - 520W max |
| Fan Tray | - Hot-swappable 5 fans, 4+1 redundancy |
| Mechanical | |
| Dimension | - 440 x 470 x 44 mm (WxDxH) |
| Weight | - 9.7 kg |
| Environmental | |
| Operating Temperature | - 0°C to 40°C |
| Operating Humidity | - 5% to 95% relative humidity noncondensing |
| Operating Altitude | - 3000m max |
| Storage Temperature | - - 40°C to 70°C |
| Storage Humidity | - 5% to 95% relative humidity noncondensing |
| Regulatory Standards Compliance | |
| Safety | - UL, cUL, CB, CCC |
| EMC | - FCC, CE, CCC |
| Available upon Request | - VCCI |
