  • Asus 2U dual-expander high-availability JBOD - VS320D-RS12J

    SKU # HS-ASU-VS320D-RS12J
    Condition # New

    Request A Quote

    Availability:
    6-8+ Weeks ETA
    Safe & Secure Checkout

    Purchase Protection

    Every Order is Protected By BuySafe

    Our commitment to sustainability ensures that every purchase supports responsible operations and a healthier planet.

    Request a Quote

    Get a personalized quote tailored to your specific needs.

    Request a Quote
    -OR-
    sales@hssl.us

    SSL Secure Payment

    We make sure your orders are processed as quickly as possible - stocked products are shipped next business day - Vendor direct ship products are processed directly with vendors with vendor leadtime.

    Express Shipping

    Price Match Guarantee

    Your payment is secure

    Your privacy and security are our top priority. Our advanced encrypted payment system protects your information during every transaction.

    Get expert help

    Our team of experienced professionals is always ready to help.

    Product Details

    2U dual-expander high-availability JBOD solution featuring up to 12 tool-less 3.5-inch SAS/NL-SAS drive bays up to 4 × JBODs for 48 drives and 1.1PB raw capacity, 5 × 12Gb/s SAS ports and supports 48Gb/s SAS wide ports, redundant architecture with power and cooling modules for SMB storage server and storage appliances capacity expansion.

    • High-availability capacity expansion: Dual-expander architecture delivers excellent throughput via 12Gb/s SAS interface and supports 48Gb/s SAS wide port, ensuring enterprise Tier2 or cold-data pools capacity expansion.
    • High-density storage: 12 front-accessible, tool-less 3.5-inch drive trays per chassis, expandable up to 48 drives and 1.1PB with JBOD cascading for growing storage needs.
    • Versatile connectivity: Five onboard 12Gb/s SAS wide ports per expander enable flexible, high-bandwidth connectivity for seamless integration with storage appliances, servers, and other JBODs.
    • Enterprise reliability: Fully redundant components, including dual expanders, redundant power supplies, fans, expansion ports, and hot-swappable drives for maximum uptime.
    • Modern simplicity: Wake-on-SAS feature for remote power management by ASUS storage appliances, and clear enclosure status indicators for easy maintenance and deployment.
    • Scale-up for capacity expansion: Ideal for SMB and enterprise storage server or storage appliances capacity scale-up environments, scenarios for backup, large-scale surveillance, and cold-data pools.
    • Architecture

      Dual-active expander
    • Storage

      12 x 3.5” hot-swap drive bays

      Compatible Drive Type:
      3.5"&2.5" SAS,NL-SAS,SED HDD/2.5"SAS,SED SSD

      Maximum Drive Bays with Expansion Unit: 420 Bays
      Drive Interface: SAS 12Gb/s

      Maximum Internal Raw Capacity:
      288 TB (calculate 24 TB HDD)

      Maximum Raw Capacity with Expansion Units:
      10,080 TB (calculate 24 TB HDD)
    • Expansion and External Port

      12Gb/s SAS Wide Port:
      5 (onboard per controller)

      USB Port:
      1(front)/2(rear)

      Others:
      Console Port x1,Service Port (UPS) x1
    • Front I/O Ports

      1 x Enclosure Status LED
      1 x Enclosure Access LED
      1 x Disk Drive Status LED
      1 x Disk Drive Power LED
      1 x Enclosure PowerButton/LED
      1 x USB Port
      1 x UID(UniqueIdentifier)Button/LED
    • Rear I/O Ports

      1 x UID(Unique Identifier) LED

      [Per node]
      12Gb/s SAS Wide Port
      12Gb/s SAS Wide Port 3 and Port 4
      12Gb/s SAS Wide Port 5
      1 x Service Port
      1 x Console Port
      1 x USB Port
      1 x Resetto Factory Default Button
      1 x Buzzer Mute Button
      1 x Seven-segment LED Display
      1 x SAS LED


    • Dimensions

      88mm x 438mm x 515mm
    • Form Factor

      2U
    • Weight

      Net Weight :16.4 kg
      Gross Weight :18.8 kg
    • System Fan

      4
    • Power Supply

      1+1 Redundant 850W 80 PLUS Platinum Power Supply
      1+1 Redundant 850W 80 PLUS Platinum Power Supply
    • Power Consumption

      407 W
    • Regulatory Compliance

      CE/ FCC/ BSMI/ CCC
    • Enviroment

      Operation temperature: 0℃ ~ 40℃
      Non operation temperature: -10℃ ~ 50℃
      Non operation humidity: 10% ~ 90% ( Non condensing)
    • Datasheet
