Product Description
Bosch Midspan 95W 1 Port Outdoor - 120 V AC, 230 V AC Input - 54 V DC Output - 1 x PoE Output Port(s) - 95 W
The 95 W midspan is a high-power PoH (Power Over HDBase T) device that provides data and power between an Ethernet switch and an IP camera.
In the table below, an "X" identifies which midspans can supply power to which models of cameras.
In the table below, an "X" identifies which midspans can supply power to which models of cameras.
Features
- Designed for outdoor installation
- Supports high-power PoE/PoH
- Lightning suppression
- Detects and protects non-standard Ethernet terminals automatically
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Package Contents
- Midspan 95W 1 Port Outdoor
- 1 x 120 -240 VAC Power Plug
- 2 x Waterproof Cap Covers for Male RJ45 Port Plugs
- 1 x Quick installation Guide
Product Type PoE Injector
Compatibility Bosch AUTODOME Camearas:
- 5000i
- 7000i
- 7000i
- 7100i
- 9000i
Input Voltage 120 V AC
Input Voltage 230 V AC
Manufacturer Part Number NPD-9501-E
Marketing Information The 95 W midspan is a high-power PoH (Power Over HDBase T) device that provides data and power between an Ethernet switch and an IP camera.
In the table below, an "X" identifies which midspans can supply power to which models of cameras.
In the table below, an "X" identifies which midspans can supply power to which models of cameras.
Packaged Quantity 1
Weight (Approximate) 4.85 lb
Certifications & Standards
- IP67
- FCC Part 15
- CE NPD-9501-E
- EN 55032 Class B (emission)
- EN 55024 (Immunity)
- VCCI
- UL
- cUL
- GR-1089-CORE
- ITU-T. K45
Form Factor Wall/Pole Mountable
Length 8.4"
Manufacturer The Bosch Group
Product Name Midspan 95W 1 Port Outdoor
Protection Type Surge Protection
Brand Name Bosch
Output Ports 1 x PoE
Country of Origin China
Height 2.8"
Width 5.9"
Environmentally Friendly Yes
Environmental Certification RoHS
Environmental Certification WEEE
Maximum Input Current 2.50 A
Maximum Output Power 95 W
Maximum Output Voltage 54 V DC
Note Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
