  • ACPF-7A24

    • Broadcom 2.4 GHz Wi-Fi Bandpass Filter for Coexistence with LTE Bands 7, 38, 40A and 41B - ACPF-7A24

    Broadcom

    Request A Quote

    Write a Review
    SKU:
    HS-BRC-ACPF-7A24
    Condition:
    New
    Availability:
    Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |
    MPN:
    ACPF-7A24
    Lifecycle:
    Active
    Distributor Inventory:
    No
    RoHS6 Compliant:
    Y
    NOTE:
    Images may not be exact, please check specifications.
    Required A Volume Purchase:
    Contact us for a volume pricing | volumeorders@hssl.us

    Product Description

    Broadcom 2.4 GHz Wi-Fi Bandpass Filter for Coexistence with LTE Bands 7, 38, 40A and 41B - ACPF-7A24

    These FBAR filters offer ultra small size, low insertion loss and high rejection. These FBAR filters have proven reliability in high power and temperature conditions.

    The Broadcom ACPF-7A24 is a Chip Scale Bandpass Filter designed for use in mobile Wi-Fi/Bluetooth applications in 2401 MHz to 2481.5 MHz. The ACPF-7A24 is compatible with high volume, lead-free SMT soldering processes and can be direct-surface mounted to a PCB or a transfer-molded module.

    Features

    • 50 ohm Input/Output
    • No external matching required
    • Low insertion loss, high interference rejection
    • Subminiature size: 0.585 mm x 0.721 mm footprint, 0.244 mm max height
    • High power rating: 27dBm max power rating (LTE modulation average)
    • Performance guaranteed  -30 to 85°C
    • RoHs 6 compliant
    • Halogen free
    • TBBPA free

    Applications

    • Wi-Fi/Bluetooth-enabled mobile communications devices operating concurrently with other wireless standards

    DATASHEET

    Other Details

    (Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.

    Product Videos

    Custom Field

    MPN ACPF-7A24
    Lifecycle Active
    Distributor Inventory No
    RoHS6 Compliant Y
    NOTE Images may not be exact, please check specifications.
    Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
