Broadcom HBA 9620-16i - Storage controller (RAID) - 16 Channel - SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe)

Overview
Other Details

Product Description

Broadcom HBA 9620-16i - Storage controller (RAID) - 16 Channel - SATA 6Gb/s / SAS 24Gb/s / PCIe 4.0 (NVMe) - RAID RAID 0, 1, 10 - PCIe 4.0 x8 - 05-50111-02

The 9620-16i Tri-Mode, PCIe Gen 4.0 enhanced HBA (eHBA) is ideal for increased connectivity and maximum performance for enterprise data center flexibility.

With increased bandwidth and IOPS performance compared to previous generations, the 9620-16i eHBA delivers the performance and scalability needed by critical applications.

Low profile, half-length x8 PCIe Gen 4.0 adapter
Connects up to 32 SAS/SATA devices or 32 NVMe devices
RAID 0/1/10 with hot spare support
Hardware Secure Boot and SPDM Attestation support
SMART monitoring
Driver temperature monitoring
Safe Store key management for attached SEDs
SFF-TA-1005 Universal Bay Management (UBM) Ready

Other Details

(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.

Product Videos

Custom Field

MPN 05-50111-02

Lifecycle Active

Brackets Full height and low profile

Data Transfer Rates 22.5, 12 and 6Gb/s SAS and 6Gb/s SATA

Host Bus Type x8 lane PCI Express 4.0

Internal Connectors 2 x8 SFF-8654 (SlimSAS)

OS Support Microsoft Windows, VMware vSphere, VMware vSphere/ESXi, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu Linux, CentOS Linux, Debian Linux, Oracle Enterprise Linux, FreeBSD

Note Images may not be exact, please check specifications.

Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
