Product Description
Broadcom Single 100GbE/Dual 40GbE PHY drives 40G/50G Serial PAM4 - BCM82251
The BCM82251 is a low-power, low-latency PHY integrating retimer and equalizer functions that support 100GbE and 40GbE applications.
In 100GbE mode, the BCM82251 converts 4 × 25GE traffic into 2 × 50GE PAM4 and is capable of driving Direct Attached Cable and SR/LR optics. In 40GbE mode, the BCM82251 converts 2 × 20GE traffic into 1 × 40GbE PAM4, and is capable of driving Direct Attached Cable and SR/LR optics. BCM82251 supports single and dual 40GbE operation. On-chip clock synthesis is performed by a low cost 156.25 MHz reference clock (for all IEEE standard 100GbE/40GbE rates) via high frequency, low-jitter phase-locked loops (PLLs).
The BCM82251 is available in 8mm × 8 mm, 0.65 mm pitch, 144-pin BGA, RoHS-compliant package.
The BCM82251 is available in 8mm × 8 mm, 0.65 mm pitch, 144-pin BGA, RoHS-compliant package.
Features
- Single chip 2x 50G PHY drives 100G over Optics or Copper Cable
- Supports both 40GE and 100GE modes
- Supports various cable reach/media
- Integrated AC Coupling Capacitors
- Line and System side Loopbacks
- Package 8mm x 8mm BGA, 0.65mm pitch
Applications
- Blade Servers
- Enterprise LAN Switching
- Line Cards
- Routers
- Servers
- Switches
- Top-of-Rack Switches
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
MPN BCM82251
Lifecycle Active
Distributor Inventory No
ASIC 57301
External Memory Interfaces 8-bit and 16-bit Flash, w/ 6 Chip Selects SRAM, NVSRAM
Link-Speeds 10Gb
Multi-Host No
NPAR No
Package 28nm, FPB4NGS, 27mmx27mm
PHY Type 100GE
Ports 1
RoCEv2 No
Smart Congestion Control No
Smart NICs No
TruFlow Yes
TruManage Yes
