Product Description
ComNet Video Receiver/Data Transceiver - Single-mode - Rail-mountable TRANSMITTER/DATA TRANSCEIVER SM
FOR BOSCH BILINXTM DOME CAMERASThe ComNet™ FVT110(M,S)1/BO is a video and data transmitter that, when paired with the FVR110(M,S)1, supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digitally encoded video and bi-directional data over one multimode or single mode optical fiber. It is for use in Bosch Bilinx™ dome cameras, utilizing time-based correction these units can achieve distances of 48km. The module also supports Bosch Bi-Phase operation, which transmits camera control information over a simplex RS-422 connection. The FVT110(M,S)1/BO is designed to plug directly into the Bosch dome, and connects with power, video input and two way data via the Bosch electrical connector.
Features
- Supports Bosch BilinxTM and Bosch Bi-phase telemetry systems
- One Data channel
- Distances up to 30 miles (48 km)
- Exceeds all requirements for RS-250C short-haul transmission: True broadcast video performance
- Time-Base Corrected Up-the-Coax Data
- Compatible with all NTSC or PAL camera systems
- Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low- line voltage conditions and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.
- Voltage transient protection on all power and signal input/ output lines provides protection from power surges and other voltage transient events.
- Automatic resettable fuses on all power lines
- Bi-color (Red/Green) LED status indicators provide rapid indication of critical operating parameters
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
Product Type Transceiver/Media Converter
Manufacturer Part Number FVT110S1
Maximum Distance Supported 29.83 Mile
Limited Warranty Lifetime
Form Factor Rail-mountable
Manufacturer ACRE
Product Name Video Receiver/Data Transceiver
Product Series FVT110(M,S)1/BO
Brand Name ComNet
Country of Origin United States
Environmentally Friendly Yes
Environmental Certification RoHS
Environmental Certification WEEE
Fiber Optic Cable Standard 9/125 µm
Media Type Supported Optical Fiber
Fiber Mode Supported Single-mode
Fiber Optic Wavelength 1310 nm
Fiber Optic Wavelength 1550 nm
Note Images may not be exact, please check specifications.
