Product Description
Dataram 32GB DDR3 SDRAM Memory Module - For Server - 32 GB (1 x 32GB) - DDR3-1600/PC3-12800 DDR3 SDRAM - 1.35 V - ECC - 240-pin - LRDIMM S26361-F3782-E517
The DRF1600LR/32G upgrade is a load reduced 4Gx72 memory module, which conforms to JEDEC's DDR3, PC3L-10600L standard. The assembly is Quad-Rank. The ranks are comprised of eighteen 2Gx4 DDP (Dual Die Pack) DDR3 SDRAMs. One 2K-bit EEPROM is used for Serial Presence Detect and an Isolation Memory Buffer, which enables higher system memory bandwidth at DDR3 speeds up to 1600 MT/s.
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type RAM Module
Compatibility Fujitsu Primergy RX200 S7 Server
Device Supported Server
Error Checking ECC
Manufacturer Part Number DRF1600LR/32GB
Number of Modules 1 x 32GB
Number of Pins 240-pin
Form Factor LRDIMM
Length 1.2"
Manufacturer Dataram Corporation
Product Name 32GB DDR3 SDRAM Memory Module
Memory Size 32 GB
Brand Name Dataram
Memory Technology DDR3 SDRAM
Memory Standard DDR3-1600/PC3-12800
Width 5.3"
Environmentally Friendly Yes
Environmental Certification RoHS
Memory Voltage 1.35 V
Note Images may not be exact, please check specifications.
