Product Description
Edgecore High-density 100/400G ports with Jericho2c+ and External TCAM Aggregation Router/Provider Edge Router/Data Center Switch - AS9947-36XKB
The AGR560 is a high-performance 400GbE aggregation router that consists of fixed 12 x 400G QSFP-DD (23 W) and 24 x 100G QSFP28 (6.5 W) network interfaces in a 2RU compact design that can be deployed as a standalone router.
The AGR560 is engineered with the Broadcom StrataDNX™ Jericho2c+ silicon leveraging external TCAMs. This platform targets use cases including 100GbE to 400GbE large aggregation router, Provider Edge (PE) router, or data center switch/router with high scalability.
The AGR560 is loaded with the Open Network Install Environment (ONIE), which supports the installation of compatible Network Operating System (NOS) soſtware, including the open-source option Open Network Linux(ONL), plus commercial NOS offerings.
Features
-
- High-performance 100GbE to 400GbE router for telecom and data center applications
- Disaggregated aggregation or PE router
- Incorporates Broadcom StrataDNX™ Jericho2c+ with external TCAMs
- Supports Synchronous Ethernet and IEEE 1588v2 PTP
- Support of high powered coherent optical transceivers up to 23W
- Application: Standalone 100GbE to 400GbE aggregation router
AS9947-36XKB
