Product Description
Experience the pinnacle of power supply performance with the EVGA SuperNOVA 650 G7. Engineered for PC enthusiasts and gamers, this PSU delivers 650 watts of continuous power with an 80 PLUS Gold certification for exceptional efficiency, ensuring minimal energy waste and reduced operating costs.
Unleash Peak Performance and Reliability
The SuperNOVA 650 G7 is built with premium components, including a durable FDB fan for near-silent operation and extended lifespan. Enjoy peace of mind with a comprehensive 10-year warranty, reflecting EVGA's unwavering commitment to quality and customer satisfaction.
Key Features:
- 80 PLUS Gold Certified: Experience up to 90% efficiency, reducing heat and electricity costs.
- Fully Modular Design: Install only the cables you need, simplifying cable management and maximizing airflow within your case.
- Quiet and Durable FDB Fan: Enjoy near-silent operation and extended lifespan with the high-performance fluid dynamic bearing fan.
- Eco Mode: Minimize fan noise at low to medium loads for ultra-quiet operation.
- Power ON Self Tester: Ensure your system's safety with the built-in self-testing feature.
- Compact 130mm Size: The shorter design easily fits in most modern PC cases.
- 10-Year Warranty: Backed by EVGA's exceptional warranty for ultimate peace of mind.
Cable Length
ATX Cable | 1x 600mm |
EPS Cable | 1x 700mm |
PCIe Cable | 1x 700mm, 1x 700mm, 850mm |
SATA Cable | 2x 550mm, 650mm, 750mm |
Four-Pin Peripheral Cable | 1x 550mm, 650mm, 750mm, 850mm |
Floppy Adapter | 1x 100mm |
AC Power | 1x 1500mm |
Modular Cable Type | Full |
Connector Quantity
24 Pin ATX | 1x 24pin |
EPS (CPU) | 1x 8pin (4+4) |
PCIe | 3x 8pin (6+2) |
SATA | 6x |
Four-Pin Peripheral | 4x |
Floppy | 1x |
Power Specs
AC Input | 100-240V~, 9-4.5A, 60/50Hz | ||||
Rail | +3.3V | +5V | +12V | +5Vsb | -12V |
Max Output | 24A | 24A | 54.1A | 3A | 0.5A |
120W | 650W | 15W | 6W | ||
Total | 650W |
Additional Details
Operating Temperature | 0° to 50° C |
Japanese Capacitors | 100% |
ECO Mode | Yes |
MTBF | 100,000 Hours |
Net Weight | 6.20 lbs |
Size | 85mm (H) x 150mm (W) x 130mm (L) |
Approvals | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 3 2014 Requirement |
Fan Size / Bearing | 120mm Fluid Dynamic Bearing |
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
MPN 220-G7-0650-X1
Brand Name EVGA
Note Images may not be exact, please check specifications.
