Product Details
Key Features
1. Dual socket R3 (LGA 2011) supports
Intel® Xeon® processor E5-2600
v4&dagger/ v3 family QPI up to 9.6GT/s
2. Up to 2TB&dagger ECC 3DS LRDIMM up to
DDR4- 2400&daggerMHz 16 DIMM slots
3. 4 PCI-E 3.0 x16 slots
2 PCI-E 3.0 x8 (1 in x16) slots
support Thunderbolt 2.0 AOC
1 PCI-E 2.0 x4 (in x8) slot
Up to 4 NVIDIA® GPU
4. I/O ports: 1 VGA 2 COM 2 GbE
10 USB 2.0 & 1 IPMI Dedicated LAN
5. 8 Hot-swap 3.5" 3 Fixed 5.25"
and 1 Fixed 3.5" Drive Bays
6. 4 Heavy Duty Fans 2 Exhaust
Fans and 2 Active Heatsink with
Optimal Fan Speed Control
7. 2000W High efficiency (96%)
Redundant PSU Titanium Level
8. Tower or Rackmount
9. GPU Kit for passive GPU/Xeon Phi
support (MCP-320-74701-0N-KIT)
| ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Titanium Level| Parts List - (Items Included) | |||
| Part Number | Qty | Description | |
| Motherboard / Chassis | MBD-X10DRG-Q | 1 | Super X10DRG-Q Motherboard |
| Backplane | BPN-SAS-747TQ | 1 | 8-port Tower/4U TQ (W/ AMI 9072) backplance support up to 8x 3.5-inch SAS/SATA HDD/SSD |
| Cable 1 | CBL-0484L | 8 | SATAINTROUNDST-ST55CM30AWG |
| Cable 2 | CBL-CDAT-0661 | 2 | CBLSGPIO2X4F TO 2X4FP2.54ROUND CABLE40CM28AWG |
| Label | LBL-0108 | 1 | CAUTION LABEL FOR REDUNDANT PWR SYSTEMS |
| Manual | MNL-1709-QRG | 1 | SYS-7048GR-TR Quick Reference GuideHFRoHS/REACH |
| Parts | MCP-260-00042-0N | 1 | STD I/O shield for X9 socket R server MB with Gasket. |
| Heatsink / Retention | SNK-P0050AP4 | 2 | 4U Active CPU Heat Sink for X9 X10 Workstations |
| Power Supply | PWS-2K04A-1R | 2 | AC-DC 2000W Titanium Level Redundancy 1U PMBus 1.2 +12V/+5Vsb 360x76x40mmHFRoHS/REACH |
| Power Distributor | PDB-PT747-4648 | 1 | Power Distributor for SC747 with graphic output feature |
| Optional Parts List | |||
| Part Number | Qty | Description | |
| Mounting Rails | MCP-290-00059-0B | 1 | Rail set+handles quick/quick optional for 4U 17.2"W tower |
| GPU Kit | MCP-320-74701-0N-KIT | 1 | GPU Kit for passive GPU/Xeon Phi support 1 kit supports up to 4 GPU |
| Cable | CBL-PWEX-0663 | 1 | PCIe 8 pin male (black) to CPU 8 pin female (white) power adapter 5cm 18AWG 1 cable per passive GPU |
| Front Bezel | MCP-210-74703-0B | 1 | Front bezel cover (for 5.25" bay) for rackmount |
| Add-on Card Dummy | MCP-240-00096-0N | 1 | GPU / Add-on Card Dummy Assembly (2 Slots)-Single Pack |
| AOC Dummy Assembly | MCP-240-00096-0N | - | SC747B GPU / Add-on Card Dummy Assembly (2 Slots)-Single Pack |
| HDD Converter | MCP-220-93801-0B | - | Black Hotswap Gen 6 3.5 to 2.5 HDD Tray (SC747 936 938 and Blade) |
| Global Services & Support | OS4HR3/2/1 | - | 3/2/1-year onsite 24x7x4 service |
| Software | SFT-OOB-LIC &bull  | 1 | OOB Management Package (per node license) |
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) |
| Add-on Card | AOC-TBT-DSL5320 | 1 | Thunderbolt 2W/Display and GPIO cableHFRoHS/REACH |
| DVD Kit | |||
| DVD-RW with Cable | DVM-LITE-DVDRW24-HBT1 | - | BLACK LITE-ON 5.25" HH 24X DVD-RW SATA DRIVE PBF |
