Product Description
HGST Ultrastar Serv24 NAS Storage System - Intel Xeon Gold 6140 Octadeca-core (18 Core) 2.30 GHz - 24 x SSD Supported - 24 x SSD Installed - 153.60 TB Total Installed SSD Capacity - 2 Boot Drive(s) - 256 GB RAM - 24 x Total Bays - 24 x 2.5" Bay - 3 x Total Slot(s) - 10 Gigabit Ethernet - VGA - 2 USB Port(s) - 2 USB 3.0 Port(s) - Network (RJ-45) - IPMI 2.0 - 2U - Rack-mountable
There is a never-ending need to increase data center performance for storage-intensive applications. The Ultrastar® Serv24 is designed to be a performance-optimized platform for software defined storage (SDS). By integrating CPUs and NVMe™ SSDs in the same unit, our storage server provides a tested and validated building block for deploying the SDS stack on high-performance storage.
Designed for Fast Data
Flash technology has revolutionized the performance of storage systems; NVMe technology extends flash storage to its full potential. Built upon our storage expertise, the Ultrastar Serv24 features the latest Intel® Xeon® CPUs. Chipset, core count and CPU power can be customized, providing the flexibility to meet varying requirements depending on data workload and performance requirements. Whether as a stand-alone file server or part of a scale-out deployment, the Ultrastar Serv24 is built to deliver screaming performance in software-defined storage environments. With low latency and consistently high bandwidth, data is accelerated to the speed of flash.Features
- Up to 184TB in a 2U unit
- Up to 24 NVMe SSDs with a range of capacities and endurance options
- High-performance Intel® "Purley"- based server with a choice of CPUs
- 2 512GB SSD boot drives
- 256GB DDR4 DRAM
- 2-port 10GbE included
- 1-port 1GbE for system management
- 2 PCIe x16 slots available for add-in cards
- Enterprise-grade redundant and hot-swappable PSUs and fan
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type NAS Storage System
Manufacturer Part Number 1ES1015
Protocols IPMI 2.0
Limited Warranty 5 Year
Standard Memory 256 GB
Weight (Approximate) 54.90 lb
Form Factor Rack-mountable
Manufacturer Western Digital Corporation
Product Name Ultrastar Serv24 NAS Storage System
Processor Speed 2.30 GHz
Processor Type Xeon Gold
Product Line Ultrastar Serv24
Rack Height 2U
Brand Name HGST
Expansion Slot Type PCI Express x16
Expansion Slot Type PCI Express x8
Processor Model 6140
Height 3.4"
Width 17.6"
Depth 29.9"
Processor Core Octadeca-core (18 Core)
Processor Manufacturer Intel
Ethernet Technology 10 Gigabit Ethernet
Number of Total Expansion Bays 24
Number of Total Expansion Slots 3
VGA Yes
Network (RJ-45) Yes
Maximum Power Supply Wattage 1200 W
Total Number of USB Ports 2
Number of USB 3.0 Ports 2
Total Solid State Drive Capacity Installed 153.60 TB
Number of Solid State Drive Supported 24
Number of Solid State Drive Installed 24
Number of 2.5" Bays 24
Number of Boot Drives 2
Note Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
