Product Description
HID EDGE EVO EHRP40-K Controller/Reader and Module, Interface to standard door – REX, DPS, lock and Wiegand / C & D reader -EHRP40-K
The EDGE EVO EHRP40-K Controller/Reader and Interface Module package is a single-door access control panel with reader and separate discrete door interface that enables cost effective installation and high performance access control functionality. The controller/reader is installed at the door and the Hi-O Interface Module is mounted separately in a secure location.
Additional highlights:
- The controller/reader and module are connected using the secure Hi-O bus and the Hi-O module provides interface to four discrete inputs and two outputs.
- The included Hi-O interface module provides interface to a second optional reader used for in/out reading.
The integrated EDGE EVO EHRP40-K Controller/Reader provides 13.56 MHz iCLASS smart card compatibility and controller logic in one device.
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Manufacturer Part Number EHRP40-K
Model EHRP40-K (82125CKI0001A)
Mounting Holes US Single-gang and EU / APAC 60mm
Dimensions 3.3" W x 4.8" H x 1.2" D(83.9 mm x 122.2 mm x 30.5 mm)
Weight 6.3oz (180g)
Operating Temperature 32° to 122° F (0° to 50° C)
Operating Humidity 5% to 95% relative, non-condensing
Communication Ports Ethernet (10/100), Hi-O CANbus, Wiegand or Clock-and-Data
DC Input (MAX) @ PoE 14.4W (300mA @ 48VDC)
DC Input (MAX) @ AUX +12VDC 18W (1500mA @ 12VDC)
DC Input (MAX) @ AUX +24VDC 36W (1500mA @ 24VDC)
Supervised Inputs Power (MAX) 0.025W (5mA sink, 5V nominal) 0 to +5VCD Ref
DC Input @ PoE 7.7W
DC Input @ AUX +12VDC 12.8W
DC Input @ AUX +24VDC 26.3W
Hi-O CANbus Output Voltage, DC Input PoE=24VDC
Hi-O CANbus Output Voltage, DC Input AUX=AUX +VDC
Note Images may not be exact, please check specifications.
