IEI Half-Size PCIe CPU Card Supports Intel Elkhart Lake Processor Intel Celeron J6412 on-Board SoC, with 8GB LPDDR4x Memory on Board Default, DDR4, HDMI, iDPM Display Module, Dual Lan, USB 3.2, SATA 6Gb/s, M.2, HD Audio and RoHS - PICOe-EHL

The PICOe-EHL delivers up to 8GB LPDDR4x-3200MHz that provides enough memory bandwidth for smooth multitasking and efficient performance. It supports multiple expansion interfaces, including one PCIe x4, four PCI, two USB 3.2 Gen2 Type-A, and two SATA 6Gb/s, enabling seamless integration with a wide range of peripherals and storage devices. This versatility allows developers to customize and scale their solutions according to specific requirements. It is suitable for embedded systems, IoT devices, and edge computing due to its low power consumption, high data transfer rate, and optimized performance balance. It also offers energy efficiency, and provides computing power and accelerated graphic processing.

Quad-Core Intel Celeron Processor J6412

Ideal for embedded applications, IEI's PICOe-EHL provides exceptional performance and energy efficiency. It has a 75% performance gain over the previous generation, up to a 1.7x improvement in single-thread performance and up to a 1.5x improvement in multi-thread performance. Its quad-core Intel Celeron J6412 SoC ensures swift processing at frequencies up to 2.6GHz, while the 1.5M cache enhances overall responsiveness. With a remarkable TDP of only 10W, this device offers unparalleled power efficiency.

8GB LPDDR4x On-Board Memory

The PICOe-EHL is equipped with robust 8GB LPDDR4x on-board memory, widely utilized for applications in high-vibration and shock-prone environments. With onboard memory, it offers flexible space utilization, enhanced reliability, and mitigates issues related to memory poor contact, making it particularly well-suited for industrial applications.

Dual Independent Displays with up to 4K Resolution

Featuring Intel UHD Graphics with a maximum of 16 execution units (EUs), this half-size PCIe CPU card offers superior graphics capabilities, enabling smooth and immersive visual experiences. Whether you are running graphics-intensive applications or demanding multimedia content, it delivers outstanding performance. Furthermore, the PICOe-EHL is capable of supporting a maximum resolution of 4kp60 across two simultaneous displays through HDMI 1.4 (up to 4096 x 2160@30Hz), and the optional iDPM module.
