  • KINO-DH310

    • IEI Mini-ITX SBC Supports 14nm LGA1151 Intel 8th/9th Generation Core i9/i7/i5/i3, Celeron and Pentium Processor, DDR4, Dual Independent Displays, Dual GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS - KINO-DH310

    IEI TECHNOLOGY

    Request A Quote

    Write a Review
    SKU:
    HS-IEI-KINO-DH310
    Condition:
    New
    Availability:
    Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |
    MPN:
    KINO-DH310
    CPU:
    LGA1151 socket supports 8th/9th generation Intel Core i9/i7/i5/i3, Pentium or Celeron processor (35W/65W)
    Chipset:
    Intel H310
    Memory:
    Two 260-pin 2666/2400 MHz Dual-Channel DDR4 SDRAM Unbuffered SO-DIMM
    Memory Max.:
    up to 64GB
    Power Consumption:
    12V@11.32A (Intel Core i7-8700 up to 4.60 GHz CPU with two 8GB 2666MHz DDR4 memory)
    Power Supply:
    DC 12V input | 1 x External DC jack (4-pin DIN) | 1 x Internal power connector (2x2 pin) | Support AT/ATX mode | ErP/EuP Compliant
    Note:
    Images may not be exact, please check specifications.
    Required A Volume Purchase:
    Contact us for a volume pricing | volumeorders@hssl.us

    Product Description

    IEI Mini-ITX SBC Supports 14nm LGA1151 Intel 8th/9th Generation Core i9/i7/i5/i3, Celeron and Pentium Processor, DDR4, Dual Independent Displays, Dual GbE LAN, M.2, SATA 6Gb/s, HD Audio and RoHS - KINO-DH310

    Features

    • LGA1151 Intel 8th/9th Generation Core i9/i7/i5/i3, Pentium or Celeron processor
    • Dual-channel DDR4 2666MHz
    • Support internal DisplayPort & Dual HDMI
    • Support M.2 A Key for WLAN expansion & M key for storage

    DATASHEET

    Other Details

    (Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.

    Product Videos

    Custom Field

    MPN KINO-DH310
    CPU LGA1151 socket supports 8th/9th generation Intel Core i9/i7/i5/i3, Pentium or Celeron processor (35W/65W)
    Chipset Intel H310
    Memory Two 260-pin 2666/2400 MHz Dual-Channel DDR4 SDRAM Unbuffered SO-DIMM
    Memory Max. up to 64GB
    Power Consumption 12V@11.32A (Intel Core i7-8700 up to 4.60 GHz CPU with two 8GB 2666MHz DDR4 memory)
    Power Supply DC 12V input | 1 x External DC jack (4-pin DIN) | 1 x Internal power connector (2x2 pin) | Support AT/ATX mode | ErP/EuP Compliant
    Note Images may not be exact, please check specifications.
    Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
