Product Details
Audio system Integrated design: The control panel integrates MIC receiver, preamplifier, audio processor, centralized controller, and power sequencer.
Complete audio system, including speakers, mic & receiver
Core Features:
- Integrated design: The control panel integrates MIC receiver, preamplifier, audio processor, centralised controller, power sequencer, etc.
- Quick Start: Press one button to power on the system
- Beam-forming Control: Adjustable beam-forming area with built-in software settings
- Audio over Ethernet: Digital Dante interface supported
- Reliable Installation: Wall-mount available for speakers
- Digital Signal Transmission: It supports Bluetooth and wireless U-band frequency audio transmission
- External Control: Supports remote control by an external control panel
- Easy Setup: Built-in power supply in the column loudspeaker and easy deployment
- Optional Accessories: MIC & control panel
- Connectivity: Supports (LINE-IN&OUT, XLR differential signal input and optical signal input)
| Weight | 32 lbs |
|---|---|
| Dimensions | 50 × 10 × 8 in |
| Brand | InVid |
CON-ARRAYSPEAKER
Specifications of Digital Active Array
Column Loudspeaker
Maximum Sound Pressure Level (SPL) 109dB SPL@1m
Total Harmonic Distortion (THD+N) ≤3% @ 1m, 0.5Vrms, 1kHz
System Noise Level NR-20
Frequency response range 150Hz~20kHz (-10dB)
Type of Enclosure Sealed
Volume of Enclosure About 2.79L
Material of Enclosure Aluminium Alloy
Number of Speakers 8pcs
Size of Speakers 2.75"
Output Power of the Amplifier 32W×8CH
Power Amplifier Specifications D type 100W/CH, 8CHs in total
Amplification Range (Horizontal) 100°
Amplification Range(Vertical) Tilting 30°-90° (Adjustable with Software)
Width 10°-110° (Adjustable with Software)
Specifications of Integrated Digital
Loudspeaker Control Panel
MIC receiver UHF with 16 Bands, Dual Channel,
Anti-oscillation
InVid Tech, reserves the right to make changes to improve our products at any time without notice; we are not responsible for misprints.
Power Sequencing Supported
Signal-to-noise Ratio
Analogue Channel: ＞85dB@500mVrms,
1kHz
Digital Channel: ＞85dB@500mVrms, 1kHz
Frequency Response 20Hz~20kHz (±1dB, in Standard Mode)
Controls Power On/Off, Volume Adjustment
Bluetooth BT5.0
EQ Standard, Conference
Specification of Microphone
Quantity 2
Style Handheld
Frequency Band
UHF 633MHz-695MHz (2 channels, each
with 16 bands are available for settings
each)
Battery AA
Electrical Specification
(Digital Active Array Column Loudspeaker)
Power Input 100V-240V AC 50Hz/60Hz 2A
Maximum Power Consumption 200W
Standby Power Consumption ≤0.5W
Electrical Specification (Control Panel)
Power Input DC 15V 1.2A
Maximum Power Consumption 18W
Standby Power Consumption ≤1W
I/O of Control Panel
USB Type A (for Debug and Update) 1
XLR IN 2
Speaker OUT (Phoenix Socket-outlet) 2
LINE IN 2
LINE OUT 2
RJ45(Dante) 4
Optical IN 1
Integrated Controller 1
Power Interface 1
Button On/Off Button, Return Button,
Confirm Button
Physical Specification
(Digital Active Array Column Loudspeaker)
Dimensions (L×W×D) 46 x 4 x 3 in (1168×98×64.7 mm)
Package Dimensions (L×W×D) 50 x 10 x 8 in (1283×265×208 mm)
Thickness (Wall Mount Included) 71.6mm
Specifications of Wall-mounted Screws TA5×40mm
Net Weight 14 lbs (6.2kg)
Gross Weight 32 lbs (14.6kg)
Physical Specification (Control Panel)*
Dimensions (L×W×D) 9 x 7 x 2 in (232×176×50 mm)
Package Dimension (L×W×D) 16 x12 x 4 in (417×306×97 mm)
Net Weight 2.7 lbs (1.25kg)
Gross Weight 6.8 lbs (3.1kg)
Accessories
Power Cable (Packaged with the Column
Speaker) ×2 (3m)
Wall Mount
(Packaged with the Column Speaker) ×2
Rack Mount
(Packaged with the Control Panel) ×3
Antenna
(Packaged with the Control Panel) ×4
Adapter
(Packaged with the Control Panel) ×1
Audio Cable
(Packaged with the Control Panel) ×1
Silicon Case for Handheld Microphone
(Packaged with the Control Panel) ×2
Documents
Quick Guide ×1
User Manual ×1
Warranty Card ×1
Environment
Operation Temperature 32°F - 104°F (0°C - 40°C)
Operation Humidity 10% - 90%RH
Storage Temperature -4°F - 140°F (-20°C - 60°C)
Storage Humidity 10% - 90%RH
Altitude Below 5000 metres
