IO Crest USB 3.0 TO HUB and Card Reader - IO-HCR7481-2UR

Product Description

IO Crest USB 3.0 TO HUB and Card Reader - IO-HCR7481-2UR

Features

• Support USB 3.0 Specification Revision 1.0.
• Support USB Specification Revision 2.0
• Upstream Port support SuperSpeed, High-Speed and Full-Speed Connections
• For Downstream Ports Support SuperSpeed, High-Speed, Full-Speed and Low-Speed Connections
• Implement USB3.0 power management function
• USB2.0 Link Power Management support
• USB Attached SCSI Protocol Revision 1.0 Compliance
• Multiple Transaction Translator Support
• Gang mode Support for Port 2, 3, 4
• Remarkable with Removable or permanently attached
• Self-power and bus-power support
• Support USB Mass Storage Class, Bulk-Only Transport Specification.
• Support USB 3.0 U0/U1/U2/U3 (P0/P1/P2/P3) and USB 2.0 L0/L1/L2 power saving modes.
• Support Secure Digital v1.0/v1.1/v2.0 SDHC/SDXC (Capacity up to 2TB).
• Support Secure Digital v3.0 UHS-I (Ultra High Speed)SDR12/SDR25/SDR50/DDR50/SDR104.
• Support MultiMediaCard (MMC) specification v4.1/v4.2 x1/x4 bit data bus and DDR x4 bit data transfer mode.
• Support user data locking, providing a privacy protection solution.
• Support SD Lock/Unlock Function.
• External Serial Flash memory interface.
• Compliant with USB bus-powered and self-powered power consumption requirements.
• Consumed less than 2.5mA  in USB 3.0 and USB 2.0 suspend mode

Package Contents

• 1 x USB3.0 HUB and Reader Controller
• 1 x User Manual
• 1 x USB3.0 Cable

Note: Contents may vary depending on country and market.

System Requirements:

• Windows Server 2003, 2008,2012
• Windows 2000/ME, XP, Vista, 7, 8
• Linux and Mac OS 9.x/10.x. or later version

Driver Installation

• Windows will automatically detect and install the drivers for the USB3.0 to Device.

Note: This device is plug-and-play, so no driver is needed.
