    • Juniper Cloud Metro Routers - ACX7100

    Juniper Networks

    Request A Quote

    Write a Review
    SKU:
    HS-JUN-ACX7100
    Condition:
    New
    Availability:
    ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |
    Width:
    17.40 (cm)
    Height:
    1.70 (cm)
    Depth:
    9.30 (cm)
    Product Type:
    Router
    Manufacturer Part Number:
    ACX7100
    System throughput:
    ACX7100-48L: 4.8 Tbps| ACX7100-32C: 4.8 Tbps
    Interface support:
    ACX7100-48L: 48x10/25/50GbE (SFP56), 6x400GbE (QSFP56-DD) ACX7100-32C: 32x40GbE (QSFP+) /100GbE (QSFP-DD), 4x400GbE (QSFP56-DD)
    Dimensions (W x H x D):
    ACX7100-48L: 17.36 x 1.75 x 23.42 in (44.09 x 4.45 x 59.49 cm) ACX7100-32C: 17.36 x 1.75 x 23.42 in (44.09 x 4.45 x 59.49 cm)
    Maximum weight:
    ACX7100-48L: 26.9 lb /12.22 kg ACX7100-32C: 28.0 lb /12.70 kg
    Power (DC):
    ACX7100-48L: -48 VDC through -60 VDC ACX7100-32C: -48 VDC through -60 VDC
    Power (AC):
    ACX7100-48L: 115/240 VAC ACX7100-32C: 115/240 VAC
    Power draw:
    ACX7100-48L, 270 W*, max 620 W (without optics) ACX7100-32C, 570 W*, max 960 W (without optics) *Typical power consumption at 25° C ambient, 50% load on all ports
    Humidity:
    ACX7100-48L: 5% to 90% non-condensing ACX7100-32C: 5% to 90% non-condensing
    Noise level:
    ACX7100-48L: 75.6 dBA at 27˚C ambient temperature ACX7100-32C: 75.6 dBA at 27˚C ambient temperature
    Operating temperature:
    ACX7100-48L: 0° to 40° C, short-term 0° to 55° C GR-63 NEBS-L3 ACX7100-32C: 0° to 40° C, short-term 0° to 55° C GR-63 NEBS-L3
    Note:
    Images may not be exact, please check specifications.
    Required A Volume Purchase:
    Contact us for a volume pricing | volumeorders@hssl.us

    Product Description

     Juniper Cloud Metro Routers - ACX7100

    Metro networks are poised for high traffic growth as operators strive to deliver secure, high-bandwidth services and excellent experiences. The ACX7100 line from Juniper ’s ACX7000 Family of sustainable routers enables service differentiation with low-latency connectivity.

    ACX7100 routers deliver 4.8-Tbps throughput in an energy-efficient 1 U footprint. They bring 10GbE-to-400GbE port flexibility to service providers, large enterprises, and data centers and support unrestricted use of high-power ZR/ZR+ transceivers.

    Powered by Junos OS Evolved  and Juniper Paragon Automation, the routers offer advanced features, such as Segment Routing (SR), SRv6, MPLS, EVPN-VXLAN, advanced programmability, network slicing, and telemetry. The ACX7100-32C model provides 40GbE, 100GbE, and 400GbE ports with MACsec on all ports; the ACX7100-48L is MEF 3.0 certified and supports a variety of 10/25/40/50/100/400GbE ports.

    Features and Benefits

    Dense Ports Distribution

    ACX7100s are high-capacity routers with dense fan-out ports ranging from 10GbE to 400GbE. The platforms enable high-end multiservice and give operators the flexibility to manage and scale their networks to meet growing requirements.



    Power Efficiency

    The compact and efficient cooling design of ACX7100 routers offers low power consumption and reduces operational costs for network operators.

    Multiservice Platform

    Address 5G, IoT, and cloud requirements with a multiservice platform that connects your residential, enterprise, wholesale, and 4G/5G customers directly to your converged and automated Juniper Cloud Metro architecture.

    One Junos Experience

    Junos OS Evolved delivers the same stability, ease of operation, and advanced programmability across the entire ACX7000 family, including the ACX7100 platforms, accelerating deployments and simplifying operations.

    Cloud Metro as Experience Sensor

    With Paragon Active Assurance agents embedded into every ACX7000 family platform, your Juniper Cloud Metro effectively becomes a sensor that monitors and measures customers’ end-to-end service experiences.

    Data Sheet

    Other Details

    (Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request page

    Product Videos

    Custom Field

    Product Type Router
    Manufacturer Part Number ACX7100
    System throughput ACX7100-48L: 4.8 Tbps| ACX7100-32C: 4.8 Tbps
    Interface support ACX7100-48L: 48x10/25/50GbE (SFP56), 6x400GbE (QSFP56-DD) ACX7100-32C: 32x40GbE (QSFP+) /100GbE (QSFP-DD), 4x400GbE (QSFP56-DD)
    Dimensions (W x H x D) ACX7100-48L: 17.36 x 1.75 x 23.42 in (44.09 x 4.45 x 59.49 cm) ACX7100-32C: 17.36 x 1.75 x 23.42 in (44.09 x 4.45 x 59.49 cm)
    Maximum weight ACX7100-48L: 26.9 lb /12.22 kg ACX7100-32C: 28.0 lb /12.70 kg
    Power (DC) ACX7100-48L: -48 VDC through -60 VDC ACX7100-32C: -48 VDC through -60 VDC
    Power (AC) ACX7100-48L: 115/240 VAC ACX7100-32C: 115/240 VAC
    Power draw ACX7100-48L, 270 W*, max 620 W (without optics) ACX7100-32C, 570 W*, max 960 W (without optics) *Typical power consumption at 25° C ambient, 50% load on all ports
    Humidity ACX7100-48L: 5% to 90% non-condensing ACX7100-32C: 5% to 90% non-condensing
    Noise level ACX7100-48L: 75.6 dBA at 27˚C ambient temperature ACX7100-32C: 75.6 dBA at 27˚C ambient temperature
    Operating temperature ACX7100-48L: 0° to 40° C, short-term 0° to 55° C GR-63 NEBS-L3 ACX7100-32C: 0° to 40° C, short-term 0° to 55° C GR-63 NEBS-L3
    Note Images may not be exact, please check specifications.
    Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
