Product Description
LevelOneGEP-0520 5-Port Gigabit PoE Switch, 802.3af PoE, 4 PoE Outputs, power adapter included, 61.6W -599009
The LevelOne GEP-0520(Z) is a high-performance Gigabit PoE Switch with 4 Gigabit PoE ports and 1 Gigabit uplink port. This switch is IEEE 802.3af compliant, and provides power and data over a single Ethernet cable to any PoE device, with total PoE power budget of 61.6W, up to 15.4W per PoE port. Together with Energy Efficient Ethernet (IEEE 802.3az) standard compliant, it substantially low power consumption during periods of low-link utilization. Moreover, it supports Gigabit Ethernet connectivity with 9K jumbo frames for network performing enhancement. Ideal for small businesses that prefer an inexpensive solution for PoE deploying infrastructure.
- 1 Gigabit port and 4 Gigabit PoE ports
- IEEE 802.3af PoE compliant to simplify deployment and installation
- 9K jumbo frames to increase data transfer rates
- Auto-detection and protection of non-standard PoE devices
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Total PoE power budget: 61.6W, up to 15.4W per port
- Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az)
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
Manufacturer Part Number 599009
Data rate Gigabit Ethernet
Dimensions (W x D x H) 120 x 90 x 28 mm
PoE Power Budget Total 61.60
Fanless Yes
Manageable No
Operating humidity 10% RH ~ 90% RH
Operating temperature 0°C ~ 45°C
Storage humidity 10% RH ~ 90% RH
Storage temperature -40°C ~ 70°C
Package Contents GEP-0520, Power Adapter, Quick Installation Guide
Power supply included Yes
Power input 48-56VDC
Power consumption 65W
Concurrent ports Total 5.00
Product weight (kg) 0.8
Color Grey
Model Number GEP-0520
