Product Description
Microchip Space Grade Radiation Tolerant DC-DC Power Converter - LE50-28-28S
The LE50-28 is an Isolated DC-to-DC converter capable of delivering up to 50W of output power in a small size design. The LE family provides a radiation Tolerant solution with excellent TID and SEE performance focusing New Space and LEO (Low Earth Orbit) applications. With forward converter topology and a patented magnetic feedback, the LE50-28 is optimized for applications where isolated DC voltage conversion is required. The discrete surface mount design facilitates customization with reasonable lead time and modest NRE cost.
To achieve MIL-STD-461 EMI compliance, an external filter is required. Off the shelf filters such as Microchip’s SF200-28-28S are available.
As a non-hybrid space grade DC-DC power converter module in the market, the LE50-28 series excels in its robustness in the New Space applications with 1.00 x106 hours of MTBF. The LE50-28 is available in 3.055” x 2.055” x 0.5” package.
Features
- Up to 50W output Power (Parallel up to 4 for higher power)
- 22VDC to 38VDC input range
- 5 output configurations available
- Up to 80% efficiency @ full load
- <1% output ripple
- Forward topology
- Patented magnetic feedback
- Adjustable output with remote adjust
- Inhibit pin for electrical ON/OFF
- Capable of paralleling up to 4 identical units
- Isolated synchronization input
- Low mass 120g
- Flight proven technology with >1Million hours of MTBF
- This product is classified as EAR99
- Customization of input/output voltages available upon request.
- TID 50krad(Si) per MIL-STD-883 Method 1019
- SEE (SEGR, SEB, SET, SEL) immunity 37MeV·cm2/mg
DATASHEET
