Product Description
The Qotom Mini PC Q750G5 S07 with Intel Bay Trail J4125 processor and 5x Intel 2.5gbe is a powerful and versatile mini PC that can be configured as a firewall, LAN or WAN router, VPN appliance, DHCP server, DNS server, and so on. It is equipped with a powerful Intel Bay Trail J4125 processor, 8GB of DDR4 RAM, and 128GB of M.2 SATA SSD storage. It also has five 2.5Gbe LAN ports, one 100Mbe LAN port, one HDMI port, one VGA port, one USB 3.0 port, two USB 2.0 ports, and one RJ45 serial port.
Here are some of the benefits of using the Qotom Mini PC Q750G5 S07:
- It is a powerful and versatile mini PC that can be configured for a variety of purposes.
- It is equipped with a powerful Intel Bay Trail J4125 processor, 8GB of DDR4 RAM, and 128GB of M.2 SATA SSD storage.
- It has five 2.5Gbe LAN ports, one 100Mbe LAN port, one HDMI port, one VGA port, one USB 3.0 port, two USB 2.0 ports, and one RJ45 serial port.
- It is easy to set up and use.
- It is backed by a one-year warranty.
Description | |
CPU | Intel Celeron Bay Trail SOC Processor, J4125 Quad core 4M Cache, 2.0 GHz Up to 2.7GHz, 10W |
Memory | Single Channel DDR4 SDRAM, Max Support to 16G |
Chipset | By CPU |
Display | Intel HD Graphics |
1 x HDMI | |
Ethernet
Mini PCIe | 5 x Intel 2.5 Gigabit LAN |
1 x Mini PCIE, Half-length for WiFi Module, or Full-length for 4G module | |
Audio | N/A |
Storage | 1 x mSATA |
USB | 2 x USB 3.0,2 x USB 2.0 |
Serial | N/A |
WatchDog | Yes |
GPIO | Yes |
RS-485 | 0 |
Power On | Yes |
Front I/O | |
Power Button | 1 |
LED | 1 x Power LED |
Display | 1 x VGA |
USB | 2 x USB 3.0,2 x USB 2.0 |
Rear I/O | |
DC-IN | 12V3A,5.5mm,2.5mm |
Ethernet | 5 x Intel 2.5 Gigabit LAN |
LED | 1 x Power LED |
Other | |
Material | Aluminum |
Dimension | 155 x 127 x 36mm |
Weight | 0.85kg |
Packaging Dimension | 261 x 218 x 75mm |
Kensington Lock | N/A |
Cooling Mode | Fanless, passitive cooling |
Mounting | VESA Mounting Bracket |
OS Support | |
OS | Windows 7,Windows 8,Windows10,Linux |
Environmental | |
Operting Temp | 0°C~50°C |
Non-Operating Temp | -20°C~80°C |
Humidity | 10%~90% |
Packlist | |
PackList | 1 x MiniPc,1 x Power supply,1 x Power cable,1 x VESA |
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
MPN Q750G5 S07
NOTE Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
