Product Description
Qotom Mini PC Q800GEX S10 - Integrated Low-Power Celeron Processor 3867U, 8 Gigabit Intel Network Cards, HDMI, DDR4 Memory, 6 Serial Port, 6 USB, Power On
The Qotom Mini PC Q800GEX S10 is a powerful and versatile computer that can be used for a variety of tasks. It features an Intel Celeron Processor 3867U, 8 Gigabit Intel Network Cards, HDMI, DDR4 Memory, 6 Serial Port, 6 USB, and Power On.
Here are some of the benefits of using the Qotom Mini PC Q800GEX S10:
- It is small and compact, making it easy to transport and set up.
- It is powered by an Intel Celeron Processor 3867U, which provides plenty of power for everyday tasks.
- It has 8 Gigabit Intel Network Cards, which allows you to connect to multiple networks simultaneously.
- It has HDMI, DDR4 Memory, 6 Serial Port, 6 USB, and Power On, making it a versatile and capable computer.
| Description | |
| CPU | Intel Celeron Kaby Lake R SOC Processor, Default 3867U Dual core 2M Cache, 1.8 GHz, 15W |
| Memory | Single Channel DDR4 2133/2400MHz SDRAM, Max Support to 16G |
| Chipset | By CPU |
| Display | Intel HD 610 |
| 1 x HDMI, 1 x VGA (Option) | |
| Ethernet | 4 x Intel I211AT Gigabit LAN |
| 4 x Intel I350 Gigabit LAN | |
| 1 x M.2 2230 for Wi-Fi Module | |
| 1 x Mini PCIE Full-length for 3G/4G Module | |
| Audio | N/A |
| Storage | 1 x mSATA for SSD，1 x SATA 3.0 |
| USB | 4 x USB 3.0，4 x USB 2.0 |
| Serial | 6 x RS-232 |
| WatchDog | Yes |
| GPIO | Yes |
| RS-485 | 2 (BIOS Option) |
| Power On | Yes |
| Front I/O | |
| Power Button | 1 |
| Reset Button | 1 |
| LED | 1 x Power LED, 1 x HDD LED |
| DC-IN | 12V3A，5.5mm，2.5mm |
| Serial | 1 x RS-232 (RJ45) |
| USB | 4 x USB 3.0，2 x USB 2.0 |
| Display | 1 x HDMI |
| Rear I/O | |
| Ethernet | 8 x Intel Gigabit LAN |
| Serial | 5 x RS-232 |
| Other | |
| Material | Aluminum |
| Dimension | 217 x 122 x 62mm |
| Weight | 2.5kg |
| Packaging Dimension | 265 x 255 x 80mm |
| Kensington Lock | None |
| Cooling Mode | Fanless, passtive cooling |
| Mounting | VESA Mounting Bracket |
| OS Support | |
| OS | Windows 7，Windows 8，Windows10，Linux |
| Environmental | |
| Operting Temp | 0°C~50°C |
| Non-Operating Temp | -20°C~80°C |
| Humidity | 10%~90% |
| Packlist | |
| PackList | 1 x MiniPc，1 x Power supply，1 x Power cable，1 x VESA |
