Raritan 1Ph, 230V Ac, 16A (16A Rated); 8 Outlets: 7X C13, 1X C19; Plug: Iec 60320 C20 (Rear Feed), 3.7Kva; Outlet Metered/Switched, 1U Horizontal Transfer Switch, Securelock Ready, Lcd Display, Ethernet, Serial, 2X Usb-A - PX3TS-5191CR-A2

Product Description

Raritan 1Ph, 230V Ac, 16A (16A Rated); 8 Outlets: 7X C13, 1X C19; Plug: Iec 60320 C20 (Rear Feed), 3.7Kva; Outlet Metered/Switched, 1U Horizontal Transfer Switch, Securelock Ready, Lcd Display, Ethernet, Serial, 2X Usb-A, Usb-B And Sensor Connections.2M Cable Length - PX3TS-5191CR-A2

The Raritan PX3TS-5191CR-A2 is a new 1U horizontal transfer switch offering reliable power distribution and management. This 1-phase, 230V AC unit supports a 16A rated current and provides 3.7kVA of power across its eight outlets (seven C13 and one C19). Featuring an IEC 60320 C20 rear feed plug, the PX3TS-5191CR-A2 allows for convenient and secure power connection. Each outlet is individually metered and switched, providing granular control and monitoring capabilities. This transfer switch is SecureLock ready for enhanced physical security, preventing unauthorized disconnections.

Managing and monitoring the PX3TS-5191CR-A2 is simplified with its integrated LCD display, providing real-time power information. Remote access and control are enabled through Ethernet and serial connections, while two USB-A ports offer additional connectivity. This Raritan transfer switch is ideal for critical applications requiring reliable power redundancy and advanced management features.

Key Features:

• Type: Horizontal Transfer Switch
• Power: 230V AC, 16A, 3.7kVA
• Outlets: 7 x C13, 1 x C19
• Connectivity: Ethernet, Serial, 2 x USB-A
• Metered/Switched Outlets: Yes
• SecureLock Ready: Yes
• Condition: New
• Weight: 20 lbs
