Product Description
ServerTech PRO2 C2XG36TE-DFME2M66 36-Outlets PDU - Switched - CS8365 3P+G 50A - 24 x IEC 60320 C13, 12 x CX - 230 V AC - Network (RJ-45) - Rack-mountable, Cabinet-mountable
The Server Technology® PRO2 Switched POPS PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® and POPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input and at each output. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched POPS "Master"PDU can be connected to as many as three (with optional module) PRO2 Switched POPS "Link"PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Package Contents
- PRO2 C2XG36TE-DFME2M66 36-Outlets PDU
- Button Mounts
Product Type PDU
Input Voltage 230 V AC
Manufacturer Part Number C2XG36TE-DFME2M66
Limited Warranty 2 Year
Input Current 50 A
Manufacturer Server Technology, Inc
Product Model C2XG36TE-DFME2M66
Product Name PRO2 C2XG36TE-DFME2M66 36-Outlets PDU
Mount Type Rack-mountable
Mount Type Cabinet-mountable
Protection Type Double Pole
Protection Type Circuit Protection
Protection Type Overload Protection
Product Series PRO2
Brand Name Server Technology
Plug/Connector Type CS8365 3P+G 50A
Country of Origin Taiwan
Height 70"
Width 2.2"
Depth 2.5"
Phase Three Phase
Receptacle Type IEC 60320 C13
Receptacle Type CX
Network (RJ-45) Yes
PDU Type Switched
Power Rating (Watt) 14.40 kW
Receptacle Detail 24 x IEC 60320 C13
Receptacle Detail 12 x CX
Note Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
