Product Description
Shure ANIUSB-MATRIX USB Audio Network Interface - ANIUSB-MATRIX
The ANIUSB-MATRIX USB Audio Network Interface from Shure is designed for audio/video conferencing installations in small- and medium-size meeting rooms. It can be used to connect 4 Microflex Advanced or Microflex Wireless microphone channels via Dante (4 in/2 out), and provide analog connectivity to a room audio/video conferencing system or a PC-based A/V conferencing application via USB (1 in/out).
An internal matrix mixer offers flexible routing, allowing users to route any input to any output. A 4-band parametric EQ filter is also available on the analog and USB outputs. The ANIUSB-MATRIX is compact and easy to mount without an equipment rack.
Features
- Connects 4 Dante audio inputs and 1 analog input to an A/V conferencing system or a PC-based videoconferencing application
- Flexible signal routing and connectivity: analog audio (1 block in/1 block out) to room A/V conferencing system; USB (1 in/out) to connect to laptop or room PC
- Power over Ethernet (PoE) eliminates the need for an outboard power supply
- Compact form factor is easy to mount without equipment rack
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
MPN ANIUSB-MATRIX
Inputs (Analog) 1 x 3-pin block connector (active balanced)
Outputs (Analog) 1 x 3-pin block connector (impedance balanced)
USB Connection 1 x USB 2.0, Type-B
Dante Connection 1 x RJ45 Channel Count: 4 inputs, 2 outputs
Polarity Non-inverting, any input to any output
Power Requirements Power over Ethernet (PoE), Class 0 (PoE Plus compatible)
Power Consumption 6.5 W maximum
Application Control HTML5 browser based
Operating Temperature Range 20 to 104°F (-6.7 to 40°C)
Storage Temperature Range 20 to 165°F (-29 to 74°C)
Thermal Dissipation Maximum: 6.8 W (23.0 BTU/hr) | Typical: 6.0 W (20.8 BTU/hr)
Note Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
