Product Description
Shuttle XPC cube SH510R4 Barebone System - Socket LGA-1200 - 1 x Processor Support - Intel H510 Chip - 64 GB DDR4 SDRAM DDR4-3200/PC4-25600 Maximum RAM Support - 2 Total Memory Slots - Serial ATA/600 Controller - Intel UHD Graphics Graphic(s) - 2 3.5" Bay(s) - 3 SATA Interface(s) - Processor Support (Core i9, Core i7, Core i5, Core i3, Pentium Gold, Celeron) - Gigabit Ethernet - Windows 10, Windows 11, Linux Supported Operating System - 4 USB 3.2 Gen 1 Port(s) - 300 W
The Shuttle XPC cube Barebone SH510R4 supports the 10th and 11th generation of Intel Core desktop processors for socket LGA1200, up to 64 GB DDR4-3200 memory, two 4K displays at 60 Hz via DisplayPort and HDMI 2.0, high-performance M.2 SSDs and up to four USB 3.2 devices. The SH510R4 can be expanded with a high-performance graphics card for demanding applications while the second PCIe-X1-slot can be used for other expansion cards. WLAN and COM port can be additionally installed as well. The SH510R4 comes with a built-in 80 PLUS power supply and Shuttle's I.C.E. heatpipe cooling which means it is en- ergy-efficient and ready for long-term operation. For a personal look and feel, the front panel can be customised by adding individual designs.
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type Barebone System
Input Voltage 120 V AC
Input Voltage 230 V AC
Manufacturer Part Number SH510R4
Maximum Memory Supported 64 GB
Weight (Approximate) 7.50 lb
Manufacturer Shuttle, Inc
Product Model SH510R4
Product Name BAREBONE XPC cube SH510R4
Processor Supported Core i9
Processor Supported Core i7
Processor Supported Core i5
Processor Supported Core i3
Processor Supported Pentium Gold
Processor Supported Celeron
Product Line XPC cube
Controller Type Serial ATA/600
Processor Socket Socket LGA-1200
Brand Name Shuttle
Operating System Supported Windows 10
Operating System Supported Windows 11
Operating System Supported Linux
Memory Technology DDR4 SDRAM
Memory Standard DDR4-3200/PC4-25600
Height 7.5"
Width 8.5"
Depth 13"
Number of External 5.25" Bays 1
Chipset Manufacturer Intel
Chipset Model H510
Graphics Controller Manufacturer Intel
Graphics Controller Model UHD Graphics
Number of SATA Interfaces 3
Number of Total Memory Slots 2
Graphics Memory Technology DDR4 SDRAM
Graphics Memory Accessibility Shared
Number of Processors Supported 1
Ethernet Technology Gigabit Ethernet
Number of Total Expansion Bays 3
Number of 3.5" Bays 2
Number of Total Expansion Slots 2
Number of PCI Express x8 Slots 1
Maximum Power Supply Wattage 300 W
Total Number of USB Ports 9
Number of Onboard USB 2.0 Ports 1
Number of VGA Ports 1
Energy Star Yes
HDMI (Rear) Yes
Product Color Black Aluminum
Number of USB 3.2 Gen 1 Ports 4
Note Images may not be exact, please check specifications.
