Product Details
Key Applications- AI / Deep Learning
- High Performance Computing (HPC)
- Cloud Gaming
- Molecular Dynamics Simulation
Key Features
1.Supports up to 8 double-width GPUs
Direct connect for maximum performance
2.Dual AMD EPYC™ 7003/7002 Series Processors
(7003 Series Processor drop-in support requires BIOS version 2.0 or newer)
3.8TB Registered ECC DDR4 3200MHz SDRAM in 32 DIMMs
4.9 PCI-E 4.0 x16
(Option: 10 PCI-E 4.0 x16 slots without NVMe devices)
5.Up to 24 Hot-swap 2.5" drive bays.
With included hardware:
• 2x 2.5" SATA in RAID 1 via onboard
Marvell 9230
• 4x 2.5" NVMe (depends on PCI-E quantity
based on #4)
RAID controller option available for 24 HDDs
6.2 GbE LAN ports (rear)
7.8 Hot-swap 11.5K RPM cooling fans
8.2000W (2+2) Redundant Power Supplies
Titanium Level (96%+)
(full redundancy based on configuration and application load)
|
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Titanium Level| Parts List - (Items Included) | |||
| Part Number | Qty | Description | |
| Motherboard / Chassis | MBD-X11DPG-OT-CPU |
1 |
Super X11DPG-OT-CPU Motherboard |
| Backplane | BPN-SAS3-216A-N4 | 1 | 24-port 2U SAS3 12Gbps hybrid backplane, support up to 20x 2.5-inch SAS3/SATA3 HDD/SSD and 4x SAS3/SATA3/NVMe Storage Devices |
| Cable 1 | CBL-0449L | 2 | HDD power extension for X8OBN, special 8 pin to 4 HDD. 45cm. 18AWG |
| Cable 2 | CBL-PWEX-1028 | 8 | GPU,2x4F/CPU to 2x4F/CPU,P4.2, 30CM,16AWG, 10A/pin, -40~105C |
| Cable 3 | CBL-SAST-0507-01 | 2 | MINI SAS HD-MINI SAS,6G,INT,80CM,SB,28AWG |
| Cable 4 | CBL-SAST-0972 | 2 | OcuLink V. 1.0 source to MiniSAS HD,INT,PCIe, 70CM,34AWG,RoH |
| Parts | MCP-130-41801-0B | 1 | Black plastic palm cover for X9DRG-O-PCIE |
| Riser Card | RSC-X9DRG-O | 4 | RSC-X9DRG-O |
| Heatsink / Retention | SNK-P0068APS4 | 2 | 2U Active CPU Heat Sink Supporting Narrow Bolster Plate Mounting Mechanism for X11 Purley Platform |
| Power Supply | PWS-2K05A-1R | 4 | 1U 2000W Redundant Titanium Power Supply W/PMbus 73.5x40x265mm,RoHS/REACH |
| FAN 1 | FAN-0199L4 | 8 | 92x92x38 mm, 11.5K RPM, SC418G Middle Fan w/ Housing,RoHS/REACH,PBF |
| Rear Window | MCP-240-84802-0N | 1 | 21 slot rear window for SC418X |
| Optional Parts List | |||
| Part Number | Qty | Description | |
| 0.5U LID | MCP-230-41803-0N | 1 | Top cover for GTX card support |
| 1U LID | MCP-230-41806-0N | 1 | Top cover for NVLINK BRIDGE support |
| 2.5" NVMe Drive Trays | MCP-220-00121-0B |
1 per drive | Black Gen-3 2.5" NVMe drive tray. Orange tab with lock |
| GPU Dummy Tray | MCP-240-00096-0N | 1 | GPU / Add-on Card Dummy Assembly (2 Slots) |
| GPU Cables | CBL-PWEX-0665 | 1 per GPU*** | GPU power cable (for NVIDIA P40, M40, M60, AMD MI25). 8pin FEMALE BLK to 8pin FEMALE WHT. 30cm 18AWG. |
| CBL-PWEX-1017 | 1 per GPU | GPU power cable (for NVIDIA QUADRO, GTX). 8pin FEMALE CPU BLUE to 2x 6pin FEMALE / 2x 1pin FEMALE. 20cm 16AWG/20AWG. | |
| CBL-PWEX-1040* | 1 per GPU | GPU power cable (for NVIDIA QUADRO, GTX). 8pin MALE CPU to 2x 6pin FEMALE / 2x 1pin FEMALE. 5cm 20AWG/16AWG. | |
| CBL-PWEX-1028** | 1 per GPU | GPU power cable (for NVIDIA TESLA V100). 8pin FEMALE CPU BLUE to 8pin FEMALE CPU BLUE. 30cm 20AWG/16AWG. | |
| Note: | * Use with CBL-PWEX-1028 ** 8 qty. included with each system *** 2 qty. required for each MI25 |
||
| Storage Control Cards and Cables | AOC-S3008L-L8I2 | 1 | Broadcom 3008 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,1E,10 |
| AOC-S3008L-L8E2 | 1 | Broadcom 3008 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, HBA only | |
| AOC-S3108-H8IR2, 4, 8 | 1 | Broadcom 3108 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60 | |
| AOC-S3108L-H8IR-16DD4, 8 | 1 | Broadcom 3108 STD LP 8 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. Maximum 16 HDD support with expander backplane | |
| AOC-SAS3-9361-16I3, 5 | 1 | Broadcom 9361 STD LP 16 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. | |
| AOC-SAS3-9361-24I5, 6 | 1 | Broadcom 9361 STD LP 24 internal ports, 12Gb/s per port - SAS HBA Adapter Card, RAID 0,1,5,6,10,50,60. | |
| CBL-SAST-0531 | 2 | n/a | |
| BTR-TFM4G-LSI004187 | 1 | LSI Remote CVKit with DVFlash Module CVFM04 for 9361 and 9380 Controller Series | |
| BTR-TFM8G-LSICVM02 | 1 | LSI Supercap w/ 8GB CV + 24" cable for LSI S3108-H8IR. Optional installation kit: - MCP-240-00127-0N - BKT-BBU-BRACKET-05 |
|
| MCP-240-00127-0N | 1 | Remote Mounting Bracket for Supercap. Installs in 2.5" drive tray. | |
| BKT-BBU-BRACKET-05 | 1 | Remote Mounting Board for Supercap. Full Height mounting bracket. Low Profile mounting bracket also included. | |
| BPN-SAS3-216EL1 | 1 | SAS3 12Gb/s Single Expander Backplane with x24 2.5" SATA/SAS HDD/SSD. | |
| Note: | 2. Requires x2 CBL-SAST-0531 3. Requires x4 CBL-SAST-0531 4. Use BTR-TFM8G-LSICVM02 for Supercap 5. Use BTR-TFM4G-LSI00418 for Cache Vault 6. Requires x6 CBL-SAST-0531 7. Requires BKT-BBU-BRACKET-05 8. Optional BPN-SAS3-216EL1 Expander Backplane support. Will lose x2 U.2 NVMe support |
||
| Network and Cables | AOC-STG-i4S | 1 | 4 Port 10G SFP+ PCI-E x8 Ethernet card. Based on Intel X710-AMI |
| AOC-STG-i2T | 1 | 2 Port 10G RJ45 PCI-E x8 Ethernet card. Based on Intel X540 | |
| AOC-S25G-B2S | 1 | 2 Port 25G SFP28 PCI-E x8 Ethernet card. Based on Broadcom BCM57414 | |
| AOC-S25G-M2S | 1 | 2 Port 25G SFP28 PCI-E x8 Ethernet card. Based on Mellanox ConnectX-4 LX EN | |
| AOC-MCX4121A-ACAT | 1 | 2 Port 25G SFP28 PCI-E X8 Ethernet card. Based on Mellanox ConnectX-4 LX EN | |
| AOC-S40G-I1Q | 1 | 1 Port 40G QSFP+ PCI-E X8 Ethernet card. Based on Intel X710 | |
| AOC-S40G-I2Q | 1 | 2 Port 40G QSFP+ PCI-E X8 Ethernet card. Based on Intel X710 | |
| AOC-MCX456A-ECAT | 1 | 2 Port 100G QSFP28 PCI-E X16 EDR IB card. Based on Mellanox Connect-4 VPI | |
| AOC-MCX556A-ECAT | 1 | 2 Port 100G QSFP28 PCI-E X16 EDR IB card. Based on Mellanox Connect-5 VPI | |
| CBL-NTWK-0944-MS28C30M | 1 | Ethernet Cable, SFP28,28GbE,PASSIVE,30 AWG,3M,Mellanox | |
| CBL-NTWK-0944-MS28C20M | 1 | Ethernet Cable, SFP28,28GbE,PASSIVE,30 AWG,2M,Mellanox | |
| AOC-E10GSFPSR | 1 | Ethernet Transceiver, SFP+ 1000Base-SX / 10GBase-SR | |
| CBL-NTWK-0446-01 | 1 | Ethernet Cable, QSFP, 40GbE, PASSIVE, 28 AWG, 3M | |
| CBL-NTWK-0942-MQ28E20M | 1 | IB Cable, QSFP28, 100GbE, PASSIVE, 28 AWG, 2M | |
| Global Services & Support | OS4HR3/2/1 |
- |
3/2/1-year onsite 24x7x4 service |
| Software | SFT-OOB-LIC • | 1 | OOB Management Package (per node license) |
| Software | SFT-DCMS-Single | 1 | DataCenter Management Package (per node license) |
