    Product Details

    Supermicro Mainstream A+ Server AS-3015A-I - UP Mid-Tower Workstation for SMB and Content Creation

    Key Applications

    • 2D/3D Content Creation
    • Email/Firewall/Application Server
    • Designed for small and medium businesses

    Key Features

    1. AMD EPYC 4004 / 4005 or Ryzen 7000 / 9000 series LGA1718 up to 170W TDP Processors
    2. 4 Dual channel ECC/Non-ECC DDR5 unbuffered DIMM slots supporting up to 192GB memory
    3. 2 PCIe 5.0 x16 (16/NA or 8/8) high-throughput slots and 2 PCIe 5.0x4 M.2 slots
    4. Dual 1GbE LAN (Intel I210-AT)

    Specifications

    Product SKUs
    A+ Server AS -3015A-I
    Motherboard
    Super H13SAE-MF
    Processor
    CPU
    • Single processor(s)
    • AMD EPYC 4004 / 4005 or AMD Ryzen 7000 / 9000 Series Processors
    Core Count
    • Up to 16C/32T
    Note
    • Supports up to 170W TDP CPUs (Air Cooled)
    GPU
    Max GPU Count
    • Up to 1 double-width GPU
    Supported GPU
    • NVIDIA PCIe: RTX 2000 Ada, RTX 4070, RTX 4000 Ada Generation, RTX A4000, RTX A2000, RTX 6000 Ada Generation
    • AMD PCIe: Radeon Pro W7500, Radeon Pro W7800
    • View GPU Options
    System Memory
    Memory
    • Slot Count: 4 DIMM slots
    • Max Memory (2DPC): Up to 192GB 5200MT/s ECC/non-ECC DDR5 UDIMM
    Memory Voltage
    • 1.1V
    On-Board Devices
    SATA
    • SATA (6Gbps) ; RAID 0/1 support
    NVMe
    • NVMe; RAID 0/1 support(Native)
    Chipset
    • AMD B650
    Network Connectivity
    • 1 RJ45 1GbE with Realtek RTL8211F PHY (dedicated IPMI)
    • 2 RJ45 1GbE with Intel I210-AT
    Input / Output
    Video
    • 1 VGA port
    • 1 HDMI 2.0b port
    • 1 DisplayPort 1.4a port
    Audio
    • Rear Audio
    System BIOS
    BIOS Type
    • AMI 32MB SPI Flash
    Management
    Software
    • SuperCloud Composer
    • Supermicro Server Manager (SSM)
    • Supermicro Update Manager (SUM)
    • Supermicro SuperDoctor 5 (SD5)
    • Super Diagnostics Offline (SDO)
    • Supermicro Thin-Agent Service (TAS)
    • SuperServer Automation Assistant (SAA) New!
    Power configurations
    • ACPI 6.0 Power Management
    Security
    Hardware
    • Trusted Platform Module (TPM) 2.0
    • Silicon Root of Trust (RoT) – NIST 800-193 Compliant
    Features
    • Supply Chain Security: Remote Attestation
    • Runtime BMC Protections
    PC Health Monitoring
    Voltage
    • +1.0V PCH, +1.8V PCH, +12V, +3.3V, +5V, +5V standby, 1.05 (PCH), 3.3V standby, 5 (4-pin), CPU, CPU temperature, CPU thermal trip support, PCH temperature, System temperature, VBAT, VRM temperature



    Chassis
    Form Factor
    • Mini-Tower
    Model
    • CSE-731i-668B
    Dimensions and Weight
    Height
    • 14.25" (362 mm)
    Width
    • 7.25" (184 mm)
    Depth
    • 16.75" (425 mm)
    Package
    • 20" (H) x 11" (W) x 21" (D)
    Weight
    • Gross Weight: 22 lbs (9.98 kg)
    • Net Weight: 18 lbs (8.16 kg)
    Available Color
    • Black
    Front Panel
    LED
    • HDD activity LED
    • Network activity LEDs
    • Power LED
    • System Overheat LED
    Buttons
    • Power On/Off button
    Port
    • USB 3.0 Port(s)
    Expansion Slots
    PCI-Express (PCIe) Configuration
    • Default
      • 1 PCIe 5.0 x16 FHFL slot
    • Option A
      • 2 PCIe 5.0 x8 FHFL slots
    Drive Bays / Storage
    Drive Bays Configuration
    • Default: Total 4 bays
      • 4 front fixed 3.5" SATA drive bays
    • Option A: Total 4 bays
      • 4 front fixed 2.5" SATA drive bays
    M.2
    • 2 M.2 PCIe 5.0 x4 NVMe slots (M-key 2280/22110)
    • View M.2 Options
    Peripheral Bays
    • 2 5.25" peripheral bays
    System Cooling
    Fans
    • 1x 90mm Fan(s)
    • 1x 80mm Fan(s)
    Air Shroud
    • 1 Air Shroud
    Power Supply
    Operating Environment
    ROHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature: 10°C to 35°C (50°F to 95°F)
    • Non-operating Temperature: -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity: 8% to 90% (Non-Condensing)
    • Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
