    • Supermicro SuperServer 1029GQ-TRT-NEBS1U NEBS Level 3 Certified Dual Processor (Intel) System with 4 GPUs (AC power)

    Supermicro

    Request A Quote

    Write a Review
    SKU:
    SYS-1029GQ-TRT-NEBS
    Condition:
    New
    Availability:
    Request A Quote | Call Us: +1 888 988 5827 Or Email: sales@hssl.us | Include your specific part number to your request. MTTR is usally within 1 Business Day 6AM-10PM EST
    MPN:
    SYS-1029GQ-TRT-NEBS
    NOTE:
    Images may not be exact, please check specifications.
    Required A Volume Purchase:
    Contact us for a special pricing for volume orders. sales@hssl.us

    Product Description

    Key Features



    1. NEBS Level 3 certified



    2. Dual Socket P (LGA 3647) support
        2nd Gen Intel® Xeon® Scalable
        processors (Cascade Lake/Skylake)‡



    3. 12 DIMMs; up to 3TB 3DS ECC
        DDR4-2933MHz† RDIMM/LRDIMM,
        Supports Intel® Optane™ DCPMM††



    4. 4 PCI-E 3.0 x16 (FHFL) slots,
        2 PCI-E 3.0 x16 (LP) slots



    5. 2 Hot-swap 2.5" SAS/SATA
        drive bays, 2 Internal 2.5" SATA drive bays



    6. Support 1x M.2 2242/2260/2280,
        Support M.2 SATA and NVMe



    7. 2x 10GBase-T LAN ports via Intel X540



    8. 9 Heavy duty 4cm counter-rotating
        fans with air shroud & optimal fan
        speed control



    9. 1300W -48Vdc single output redundant
        power supplies



    Specifications

    Product SKUs

    SYS-1029GQ-TRT-NEBS-DC
    • SuperServer 1029GQ-TRT-NEBS-DC

    Motherboard


    Super X11DGQ

    Processor

    CPU
    • Dual Socket P (LGA 3647)
    • 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
      3 UPI up to 10.4GT/s
    • Support CPU TDP up to 165W
    Cores
    • Up to 28 Cores
    Note ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R).

    Extended thermal solutions may be required to support CPUs higher than 165W TDP, please contact Supermicro Technical Support for additional information.

    GPU

    Supported GPUs
    • 4 Double-Width/Single-Width PCI-E 3.0 x16 Card (Full Height Full Length)
    • NVIDIA V100, V100S
    • Compatible GPU list
    CPU-GPU Interconnect
    • PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root

    System Memory

    Memory Capacity
    • 12 DIMM slots
    • Up to 3TB 3DS ECC DDR4-2933MHz† RDIMM/LRDIMM
    • Supports Intel® Optane™ DCPMM††
    Memory Type
    • 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM
    Note † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
    †† Cascade Lake only. Contact your Supermicro sales rep for more info.

    On-Board Devices

    Chipset
    • Intel® C621 chipset
    SATA
    • SATA3 (6Gbps) with RAID 0, 1, 5, 10
    Network Connectivity
    • Intel® X540 Dual Port 10GBase-T
    • Virtual Machine Device Queues reduce I/O overhead
    • Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
    IPMI
    • Support for Intelligent Platform Management Interface v.2.0
    • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
    Graphics
    • ASPEED AST2500 BMC

    Input / Output

    SATA
    • 4 SATA3 (6Gbps) ports
    LAN
    • 2 RJ45 10GBase-T ports
    • 1 RJ45 Dedicated IPMI LAN port
    USB
    • 2 USB 3.0 ports (rear)
    Video
    • 1 VGA port
    Serial Header
    • 1 Fast UART 16550 header

    System BIOS

    BIOS Type
    • AMI 32Mb SPI Flash ROM

    Management

    Software
    Power Configurations
    • ACPI / APM Power Management

    PC Health Monitoring

    CPU
    • Monitors for CPU Cores, Chipset Voltages, Memory.
    • 4+1 Phase-switching voltage regulator
    FAN
    • Fans with tachometer monitoring
    • Status monitor for speed control
    • Pulse Width Modulated (PWM) fan connectors
    Temperature
    • Monitoring for CPU and chassis environment
    • Thermal Control for fan connectors

    Chassis

    Form Factor
    • 1U Rackmount
    Model
    • CSE-118GQETS-R0NP2

    Dimensions and Weight

    Height
    • 1.7" (43mm)
    Width
    • 17.2" (437mm)
    Depth
    • 35.2" (894mm)
    • 39.3" (997mm) with rails
    Package
    • 24" (H) x 8" (W) x 46" (D)
    Weight
    • Net Weight: 45 lbs (20.4 kg)
    • Gross Weight: 58 lbs (26.31 kg)
    Available Color
    • Black

    Front Panel

    Buttons
    • Power On/Off button
    • System Reset button
    LEDs
    • Power LED
    • Hard drive activity LED
    • Network activity LEDs
    • System Overheat LED / Fan fail LED /
      UID LED

    Expansion Slots

    PCI-Express
    • 4 PCI-E 3.0 x16 (FHFL) slots - supporting up to 4 GPUs
    • 2 PCI-E 3.0 x16 (LP) slots

    Drive Bays

    Hot-swap
    • 2 Hot-swap 2.5" SAS/SATA drive bays
    Fixed
    • 2 Internal 2.5" SATA drive bays
    M.2
    • Support 1x M.2 2242/2260/2280
    • Support M.2 SATA and NVMe


    System Cooling

    Fans
    • 9 Heavy duty 4cm counter-rotating fans with air shroud & optimal fan speed control

    -48Vdc Input Redundant Power Supplies

    1300W DC48V Redundant Power Supplies
    Total Output Power
    • 1300W: -44Vdc to -65Vdc
    Dimension
    (W x H x L)
    • 73.5 x 40 x 265 mm
    +12V
    • Max: 108.3A / Min: 0A (-44 to -65Vdc)
    +12Vsb
    • Max: 2.1A / Min: 0A
    Output Type
    • 25 pair Gold Finger

    Operating Environment

    RoHS
    • RoHS Compliant
    Environmental Spec.
    • Operating Temperature:
         10°C ~ 35°C (50°F ~ 95°F)
    • Non-operating Temperature:
         -40°C to 60°C (-40°F to 140°F)
    • Operating Relative Humidity:
         8% to 90% (non-condensing)
    • Non-operating Relative Humidity:
         5% to 95% (non-condensing)<

    Parts List

    NEBS Tested Parts List

      Part Number Qty Description
    CPU P4X-CLX6240-SRF8X 2 Cascade lake 6240 Processors
    Memory MEM-DR480L-HL05-ER26

    MEM-DR480L-HL01-ER29

    MEM-DR432L-CL01-ER29

    MEM-DR464L-SL01-ER29    		 - 8GB - DDR4 – 2666 Hynix

    8GB - DDR4 – 2933 Hynix

    32GB - DDR4 – 2933 Micron

    64GB – DDR4 – 2933 Samsung
    Hard Drives HDS-M2T-MTFDDAK480TDN1AT - Micron 5200 – 480GB
    HDS-M2T-MTFDDAK480TDT1AW - Micron 5300 Max – 480GB
    HDS-S2T1-MZ7LH7T6HMLA05 - Samsung – 7.68TB
    HDS-X2T-XA960ME10063 - Seagate – 960GB
    HDS-I2T0-SSDSC2KG038T8 - Intel – 3.84TB
    GPUs GPU-NVTV100-16

    GPU-NVTV100-32

    GPU-NVTV100S-32    		 - Tesla V100 16GB

    Tesla V100 32GB

    Tesla V100S 32GB
    Add on Cards AOC-STG-I4S-P - Standard LP 4-port 10G SFP+
    Software SFT-DCMS-Single - Supermicro System Managment Software license,HF,RoHS/REACH,PBF
