Product Description
Supermicro SuperServer 8049U-E1CR4T Barebone System - 4U Rack-mountable - Socket P LGA-3647 - 4 x Processor Support - Intel C621 Chip - 12 TB DDR4 SDRAM DDR4-2933/PC4-23466 Maximum RAM Support - 48 Total Memory Slots - Serial ATA/600 RAID Supported, 12Gb/s SAS Controller - ASPEED AST2500 Graphic(s) - 24 3.5" Bay(s) - Processor Support (Xeon Platinum, Xeon Gold, Xeon Silver, Xeon Bronze) - 10 Gigabit Ethernet - Intel Optane Memory Ready - 2 USB 3.0 Port(s) - 4 x 1600 W - 3 Year.
Scalable Processors + C621 based SuperServer / Socket P - LGA 3647 / DP Xeon
4U Xeon® Scalable Processors
Supermicro 4-Way & 8-Way MP systems offer the highest levels of performance, efficiency and security, as well as essential RAS functions. With a focus on single-node scalability, these systems provide the largest processor and memory configurations available.
4U Xeon® Scalable Processors
Supermicro 4-Way & 8-Way MP systems offer the highest levels of performance, efficiency and security, as well as essential RAS functions. With a focus on single-node scalability, these systems provide the largest processor and memory configurations available.
Features
- 4-Way MP
- Up to 112 cores per system
- In-Memory Database Application
- ERP, CRM
- Business Intelligence
- Scientific Computing
- Scale-up HPC
- Cloud and Virtualization needs
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type Barebone System
Input Voltage 120 V AC
Input Voltage 230 V AC
Manufacturer Part Number SYS-8049U-E1CR4T
Maximum Memory Supported 12 TB
Limited Warranty 3 Year
Weight (Approximate) 74.49 lb
Form Factor Rack-mountable
Manufacturer Supermicro Computer, Inc
Product Model 8049U-E1CR4T
Product Name SuperServer 8049U-E1CR4T (Black)
Processor Supported Xeon Platinum
Processor Supported Xeon Gold
Processor Supported Xeon Silver
Processor Supported Xeon Bronze
Product Line SuperServer
Controller Type Serial ATA/600
Controller Type 12Gb/s SAS
Processor Socket Socket P LGA-3647
Rack Height 4U
Brand Name Supermicro
Memory Technology DDR4 SDRAM
Memory Standard DDR4-2933/PC4-23466
Height 6.9"
Width 17.2"
Depth 34.5"
Environmentally Friendly Yes
Environmental Certification RoHS
64-bit Processing Yes
Chipset Manufacturer Intel
Chipset Model C621
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2500
Number of Power Supplies Installed 4
Number of Total Memory Slots 48
Number of Processors Supported 4
RAID Supported Yes
Ethernet Technology 10 Gigabit Ethernet
Number of Total Expansion Bays 24
Number of 3.5" Bays 24
Number of Total Expansion Slots 16
Number of PCI Express x8 Slots 10
Number of PCI Express x16 Slots 6
Maximum Power Supply Wattage 1600 W
Total Number of USB Ports 2
Number of USB 3.0 Ports 2
Intel Optane Memory Ready Yes
Product Color Black
Note Images may not be exact, please check specifications.
