Ubiquiti Unifi Cloud Gateway Fiber - Desktop 10G Cloud Gateway With Integrated 4-Port 2.5 Gbe Switch, Selectable NVR Storage, And Full Unifi Application Support

Ubiquiti

SKU:

HS-UBI-UCG-Fiber (30W)

Condition:

New

Availability:

Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |

Dimensions:

212.8 x 127.6 x 30 mm, (8.3 x 5 x 0.5 ")

Network:

Yes

Protect:

Yes

Access:

Yes

Talk:

Yes

Connect:

Yes

Managed UniFi Devices:

50+

Managed Cameras:

(15) HD, (8) 2K, (5) 4K

Simultaneous Users Connected:

500+

Default WAN Ports:

(1) 10G SFP+, (1) 10 GbE RJ45

LAN Ports:

(1) 10G SFP+, (4) 2.5 GbE RJ45

IDS/IPS Throughput:

5 Gbps

Form Factor:

Compact desktop

Stateful Firewall:

Yes

Application-Aware Layer 7 Firewall:

Yes

DPI & Traffic Identification:

Yes

Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps):

Yes

Content Filtering:

Yes

Intrusion Prevention (IPS/IDS):

Yes

Ad Blocking:

Yes

IDS/IPS Signatures:

55,000+ with CyberSecure

VLAN/Subnet-based Traffic Segmentation:

Yes

License-Free SD-WAN:

Yes

Site Magic:

Yes

IPsec:

Yes

OpenVPN:

Yes

Identity Endpoint One-Click VPN:

Yes

Teleport Zero-Configuration VPN:

Yes

WireGuard:

Yes

L2TP:

Yes

Multi-WAN Load Balancing:

Yes

Dynamic Routing (OSPF):

Yes

Advanced QoS:

Yes

Multicast DNS (mDNS):

Yes

Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT):

Yes

Integrated RADIUS Server:

Yes

RADIUS over TLS (RadSec):

Yes

Additional Internet Failover with UniFi LTE Backup:

Yes

Internet Quality and Outage Reporting:

Yes

MAC Address Table Size:

4,000

NVR Storage:

Selectable NVMe SSD up to 2 TB

PoE Budget:

30W

Voltage Range PoE Mode:

50-57V

Max. Power Consumption:

29.4W (Excluding PoE output)

Power Method:

DC jack (54V DC/1.1A)

Power Supply:

54V DC/1.1A (adapter included)

Supported Voltage Range:

100-240V AC

Processor:

Quad-core ARM® Cortex®-A73 at 2.2 GHz

System Memory:

3 GB

Enclosure Material:

Polycarbonate

LCM Display:

0.96" status display

Management:

Ethernet, Bluetooth

LEDs System:

Yes

ESD/EMP Protection:

Air: ± 8kV, contact: ± 4kV

Ambient Operating Temperature:

-10 to 40° C (14 to 104° F)

Ambient Operating Humidity:

5 to 95% noncondensing

Certifications:

CE, FCC, IC

Button:

(1) Factory-reset

VLAN:

802.1Q

Guest Traffic Isolation:

Yes

UniFi Network:

Version 9.0.108 and later

Note:

Images may not be exact, please check specifications.
