Product Description
Vertiv Avocent LV5500 High-Performance KVM Extender | Receiver - High-Performance KVM Extender | 4K 60Hz | Single Head | Dual Head | Single Port KVM | 2 Port KVM | 4 Port KVM | 4K DisplayPort | USB 2.0 | True USB Emulation | DVI KVM Switch | Fiber Optic | High Resolution Display
The Vertiv Avocent LongView 5500 Receiver (LV5500R) is the latest in the Avocent high-performance family of products. Coupled with the Avocent LV5500T, the LV5500R is a point-to-point high performance KVM extender that provides 24-bit color graphics over a single head up to 4K@60Hz. Along with providing real-time access, local port pass through, and HD analog audio, the LV5500R provides an effortless and automatic connection for up to two users, local and remote, over the IP network without the need for extensive manual setup. Increase business security with signed upgrade files and firmware updates from a single USB flash drive. The LV5500R is ideal for broadcasting, control centers, and other industries requiring high performance, 4K video.
Features
- Delivers seamless KVM control and 4k video transmission.
- Allows for greater distance with the Fiber Option.
- Provides ultra-high-resolution video images for single-monitor and high-res video for dual-head.
- Plug-and-play with no drivers or software to install, and no on-site configuration required.
- Faster throughput with updated USB.
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
Product Type KVM Extender Receiver
Input Voltage 120 V AC
Input Voltage 230 V AC
Manufacturer Part Number LV5500R-400
Packaged Quantity 1
Platform Supported PC
Platform Supported Unix
Platform Supported Mac
Platform Supported Sun
Platform Supported Linux
Limited Warranty 2 Year
Connectivity Technology Wired
Form Factor Rack-mountable
Manufacturer Vertiv
Microphone Yes
Product Model LV5500R
Product Name LV5500 High-Performance KVM Extender | Receiver
Power Consumption 18 W
Product Line LongView
Product Series 5000
Rack Height 1U
Brand Name AVOCENT
Input Voltage Range 100-240 VAC
Country of Origin United Kingdom
Environmentally Friendly Yes
Environmental Certification China RoHS
Maximum Video Resolution 4096 x 2160
Graphic Mode 4K
Maximum Operating Distance 13123.36 ft
USB Yes
HDMI No
Number of HDMI Ports 0
DVI No
VGA No
Headphone Yes
Number of Network (RJ-45) Ports 1
Network (RJ-45) Yes
Number of USB Ports 2
DisplayPort Yes
Proprietary Interface No
PS/2 Port No
Number of PS/2 Ports 0
Number of VGA Ports 0
Number of DVI Ports 0
KVM Technology Digital
Number of Computers Supported 1
Number of Local Users Supported 1
Number of Remote Users Supported 1
Receiver Height 1.54"
Receiver Width 7.32"
Receiver Depth 5.83"
Receiver Weight (Approximate) 2.73 lb
TAA Compliant Yes
Device Type High Performance KVM
Product Color Black
Note Images may not be exact, please check specifications.
