Zebra 3600 DS3678-HP Barcode Scanner Kit - DS3678-HPU42P-10

Zebra

Request A Quote

SKU:

HS-ZEB-DS3678-HPU42P-10

Condition:

New

Availability:

Vendor Direct Ship | ETA - Request A Quote | Email: sales@hssl.us | Call Us: +1 888 988 5472 |

Width:

3.00 (cm)

Height:

7.30 (cm)

Depth:

5.20 (cm)

Application/Usage:

Industrial

Application/Usage:

Warehouse

Application/Usage:

Manufacturing

Application/Usage:

Outdoor

Battery Chemistry:

Lithium Ion (Li-Ion)

Package Contents:

• 3600 DS3678-HP Barcode Scanner Kit
• Cradle STB3678-C110F3WW
• USB Cable CBA-U42- S07ZAR
• Power Supply PWR-BGA12V50W0WW
• DC Line Cord CBL-DC-451A1-01
• AC Line Cord 23844-00-00R

Host Interface:

USB

Product Type:

Barcode Scanner Kit

Manufacturer Part Number:

DS3678-HPU42P-10

Limited Warranty:

36 Month

Weight (Approximate):

10.90 oz

Connectivity Technology:

Cable

Durability:

Dust Proof

Durability:

Water Proof

Durability:

Drop Resistant

Features:

Beep

Features:

Vibration

Features:

Notification LED

Features:

Data Formatter

Form Factor:

Handheld

Manufacturer:

Zebra Technologies Corporation

Product Model:

DS3678-HP

Product Name:

3600 DS3678-HP Barcode Scanner Kit

Product Series:

3600

Brand Name:

Zebra

Scanning Distance:

80

Light Source:

Laser

Height:

7.3

Width:

3

Depth:

5.2

Battery Capacity:

3100 mAh

Bluetooth:

Yes

Drop Specification:

• Withstands multiple 8.0 ft/2.4 m drops to concrete at -20° C to 50° C

Image Sensor Type:

Imager

Illumination Type:

LED

Standby Current:

100 mA

Scan Mode:

Trigger

Storage Temperature:

-40°F (-40°C) to 158°F (70°C)

Product Color:

Industrial Green

Power Supply Included:

Yes

Color Family:

Green

Illumination Color:

White

Ingress Protection (IP) Rating:

IP65

Ingress Protection (IP) Rating:

IP68

Rugged:

Yes

Cable Type Included:

USB

Field of View (Horizontal):

31°

Field of View (Vertical):

23°

Reading Angle (Skew):

60°

Reading Angle (Pitch):

60°

Reading Angle (Roll):

360°

Maximum Ambient Light:

108000 lux

Minimum Print Contrast:

15%

Minimum Element Resolution (DataMatrix):

7.5 mil

Maximum Element Resolution (DataMatrix):

10 mil

Air Electrostatic Discharge (+/-):

25kV

Image Sensor Resolution:

1280 x 960

Humidity (Non-condensing):

5% to 95%

Environmental Compliance:

Restriction of Hazardous Substances (RoHS)

Note:

Images may not be exact, please check specifications.

Required A Volume Purchase:

Contact us for a volume pricing | volumeorders@hssl.us
