Product Description
Wisenet PNV-A6081R 2 Megapixel HD Network Camera - Dome - 131.23 ft Night Vision - H.265, H.264, MJPEG - 1920 x 1080 - 4.38 mm Varifocal Lens - 2.1x Optical - CMOS - Roof Mount, Wall Mount, Ceiling Mount, Pole Mount, Corner Mount, Parapet Mount - Vandal Resistant AI CAMERA
Reducing false alarm based on deep learning technology
Wisenet AI cameras using AI algorithms filter out irrelevant movements caused by environmental changes such as waving trees, shadows, or animals. While conventional cameras detect motion based on its pixels and generate events even if users want to ignore, Deep Learning-based Wisenet AI cameras generate event alarm only for people and vehicles, reducing false alarms for more efficient operation.
Attribute, BestShot for the forensic search
Metadata including attribute (people : age, gender, colors of top/bottom clothes, wearing glasses, Vehicle : types, colors) is sent to the backend server and used to extract information on specific situations, significantly reducing the time to search the entire video. And Wisenet P series AI cameras are equipped with the BestShot feature for re-identification which ensures that only the most suitable images of classified objects are sent to the backend server.
Wisenet P seires AI cameras can also quickly and accurately detect the objects with or without face mask and immediately sends out alert.
VMS Integration for forensic search applications
Wisenet P series AI cameras offers integration of video management system from Milestone, Genetec using Hanwha Techwin's AI Plug-ins and Wisenet WAVE. These Plug-ins provide improved AI search on Milestone and Genetec's video management system.
Free AI powered COVID-19 Solutions
Wisenet P series AI cameras supports free AI based COVID-19 Solutions including the Occupancy Monitoring Application, Face Mask Detection, and Social Distancing Detection.
- Max. 2MP resolution, Up to 120fps
- 0.007Lux@F1.3, 1/30sec. (Color), 0Lux (B/W, IR LED on)
- Day & Night (ICR), WDR (120dB), WiseNRⅡ (Using AI engine)
- H.265, H.264, MJPEG, WiseStreamⅡ, WiseStreamⅢ (Using AI engine)
- Video Analytics based on AI - Object detection and classification (Person, Face, Vehicle, License Plate) - Face mask detection, Social distancing detection - Attribute, BestShot
- Compatible with Wisenet Retail Insight v2.0 for Business Intelligence - Age/gender based People counting - Heatmap, Queue management
- TPM with FIPS 140-2 level2, Secure boot, Verify firmware forgery
- System requirements - SSM v2.10.8 or later, Genetec plugin v1.0 or later, Milestone plugin v1.0.2 or later, NVR model (XRN-6410DB4/B4, XRN-3210B4)
- Hard-coated dome bubble/IP66, IP67, IP6K9K, IK10+, NEMA4X
Input Voltage | 12 V DC |
Storage Type | Memory Card |
Longest Shutter Speed | 1/5 Second |
Shortest Shutter Speed | 1/12000 Second |
Minimum Operating Temperature | -58°F (-50°C) |
Maximum Operating Temperature | 131°F (55°C) |
Operating Humidity | 90% |
Connectivity Technology | Wired |
Wired | |
Remote Management | Yes |
Recording Formats | HD |
HD Recording | Yes |
Night Vision Distance | 131.23 ft |
Color Supported | Color |
Image Sensor Type | CMOS |
Effective Camera Resolution | 2 Megapixel |
Field of View | H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele) |
Features | Automatic White Balance |
Wide Dynamic Range | |
Shock Detection | |
Motion Detection | |
Alarm Triggering | |
Audio Detection | |
Microphone In | |
Back Light Compensation (BLC) | |
Day/Night | |
Digital Image Stabilization | |
Digital Noise Reduction | |
Enter/Exit Detector | |
Face Detection | |
Gain Control | |
Impact Protection Rating | IK10 |
Ingress Protection Rating | IP66 |
IP6K9K | |
IP67 |
Video Formats | MJPEG |
H.264 | |
H.265 | |
Maximum Video Resolution | 1920 x 1080 |
Maximum Frame Rate | 120 fps |
Lens Type | Varifocal |
Optical Zoom | 2.1x |
Maximum Aperture | f/2.15 |
Maximum Focal Length | 9.33 mm |
Minimum Focal Length | 4.38 mm |
Minimum Aperture | f/1.3 |
Lens Included | Yes |
Product Type | Network Camera |
Manufacturer Part Number | PNV-A6081R |
Manufacturer Website Address | http://www.hanwha.com |
Manufacturer | Hanwha Group |
Product Model | PNV-A6081R |
Product Name | 2MP Network AI IR Vandal Dome Camera |
Product Series | P |
Brand Name | Wisenet |
Weight (Approximate) | 4.19 lb |
Color | White |
Durability | Vandal Resistant |
Form Factor | Dome |
Mount Type | Pole Mount |
Wall Mount | |
Roof Mount | |
Parapet Mount | |
Corner Mount | |
Ceiling Mount | |
Diameter | 7.1" |
