Product Description
- Dimensions&Miscellaneous
Model: MBD-X11SSH-LN4F Width: 9.6 Inch Depth: 9.6 Inch - Primary Information
Mainboard Form Factor: Micro ATX Mainboard / Chipset Type: Intel C236 Compatible Processors: Intel Celeron, Intel Pentium, Intel 7th/6th Generation Core i3 series, Intel Xeon processor E3-1200 v6/v5 Features: 8 SATA3 (6Gbps) via C236; RAID 0, 1, 5, 10; Quad GbE LAN with Intel i210-AT - Processor
Processor / Socket Type: LGA1151 - Memory
RAM / Technology: DDR4 Data Integrity Check: ECC - Storage
Controller Interface Type: SATA III - Expansion
Expansion Slots Total (Free): 1 PCI-E 3.0 x8 (in x16 slot), 1 PCI-E 3.0 x8, 1 PCI-E 3.0 x4 (in x8 slot) Interfaces & Connections: 3 USB 3 port(s) (1 Type A; 2 via header); 6 USB 2.0 port(s) (4 via header; 2 rear); 2 USB 3.0 port(s) (2 rear); 1 VGA port(s); 2 COM Port(s) (1 header; 1 rear) - UNSPSC Code
UNSPSC Code: 43201513
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445.Product Videos
Custom Field
Product Type Server Motherboard
MPN MBD-X11SSH-LN4F-O
Maximum Memory Supported 64 GB
Form Factor Micro ATX
Manufacturer Supermicro Computer, Inc
Product Model X11SSH-LN4F
Product Name X11SSH-LN4F Server Motherboard
Package Type Retail
Processor Supported Core i3
Processor Supported Celeron
Processor Supported Pentium
Processor Supported Xeon
RAID Levels 0
RAID Levels 1
RAID Levels 5
RAID Levels 10
Total Processor Supported 1
Controller Type Serial ATA/600
Processor Socket Socket H4 LGA-1151
Brand Name Supermicro
Memory Technology DDR4 SDRAM
Width 9.6"
Depth 9.6"
Chipset Manufacturer Intel
Chipset Model C236
Number of Memory Slots 4
Graphics Controller Manufacturer ASPEED
Graphics Controller Model AST2400
Gigabit Ethernet Yes
Number of SATA Interfaces 8
Onboard Video On-board Video Chipset
RAID Supported Yes
Number of Total Expansion Slots 3
Number of PCI Express x8 Slots 2
Number of PCI Express x16 Slots 1
VGA Yes
Total Number of USB Ports 4
Number of USB 3.0 Ports 2
Total Number of Onboard USB Ports 7
Number of Onboard USB 3.0 Ports 3
Total Number of PCI Express Slots 3
Memory Form Factor DIMM
Memory Form Factor UDIMM
Memory Speed Supported 2133 MHz
Memory Speed Supported 1866 MHz
Memory Speed Supported 1600 MHz
Note Images may not be exact, please check specifications.
