Product Description
Dataram 32GB DDR4 SDRAM Memory Module - 32 GB (1 x 32GB) - DDR4-2933/PC4-23466 DDR4 SDRAM - 2933 MHz - 1.20 V - ECC - Registered - 288-pin - DIMM
DTM68150-M is a registered 4Gx72 memory module, which conforms to JEDEC's PC4-2933Y standard. The assembly is Dual-Rank with each rank containing of eighteen Micron 2Gbx4 DDR4-2933Y SDRAMs. One 4K-bit EEPROM is used for Serial Presence Detect and a combination register/PLL, with Address and Command Parity, is also used.
Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology. A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C
Both output driver strength and input termination impedance are programmable to maintain signal integrity on the I/O signals in a Fly-by topology. A thermal sensor accurately monitors the DIMM module and can prevent exceeding the maximum operating temperature of 95C
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type RAM Module
Error Checking ECC
Manufacturer Part Number DTM68150-M
Number of Modules 1 x 32GB
Number of Pins 288-pin
Signal Processing Registered
Thickness 156.7 mil
Form Factor DIMM
Length 5.3"
Manufacturer Dataram Corporation
Memory Speed 2933 MHz
Product Name 32GB DDR4 SDRAM Memory Module
Memory Size 32 GB
Brand Name Dataram
Memory Technology DDR4 SDRAM
Memory Standard DDR4-2933/PC4-23466
Width 1.2"
Memory Voltage 1.20 V
