Product Description
Juniper 100G-SR4 ETHERNET ONLY QSFP28 MODULE
Part Number
740-058734
Speed
4 x 25 Gigabit Ethernet, 100 Gigabit Ethernet
Breakout Capable
Yes
Breakout cables
MTP-4LC-M1M, MTP-4LC-M3M, MTP-4LC-M5M, MTP-4LC-M10M can be used as break-out cables
Transceiver Type
QSFP28
Product Type
Optical Transceiver
Connector
MPO-12
Monitoring Available
Yes
Digital Optical Monitoring
Yes
Standard: 100GBASE-SR4
Standards compliance (Ethernet/OTN Standard, for e.g. 100GBASE-LR4)
100GBASE-SR4 (Clause 95)
Diagnostic support
Yes
Signaling rate, each lane
25.78125 GBd +/- 100 ppm
Transmitter wavelengths (range)
840 nm through 860 nm
Receive lane wavelengths (range)
840 nm through 860 nm
Transmitter output power, each lane (minimum)
–8.4 dBm
Transmitter output power, each lane (maximum)
2.4 dBm
Receiver input power, each lane (minimum)
–10.3 dBm
Receiver input power, each lane (maximum)
2.4 dBm
Cable type
MMF
Core size/cladding
50/125 µm
Fiber grade
OM3
OM4
Effective modal bandwidth
2000 MHz x km
4700 MHz x km
Distance
70 m
100 m
Operating Temperature (range)
0° C to 70° C
Storage temperature
–40° C to 85° C
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. to receive a custom quote on your specific configuration or part/service number not find on our online catalogue. Financing Options Available for all USA customersProduct Videos
Custom Field
NOTE Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
MPN QSFP-100GBASE-SR4,
