Product Description
163 inch All In One LED Display wih Quad SMD Technology, 1080p native / 4K compatible, 600nits, image size 163, 432lbs, 1.9mm pitch 2x HDMI In, VGA, HDBaseT, 2xUSB 2.0 1x USB 3.0, WiFi, LAN, RS232, Audio Out, 225 tiles, OPS compatible (same as 5 series), Mounting cart (Optional). Warranty: 2-year limited warranty
- Screen size: 163-inch
- Brightness: 600 nits (calibrated)
- Native resolution: 1080p Full HD (1920 x 1080)
- Smooth screen surface and 170° wide viewing angle with robust 4-in-1 SMD LED
- Stunning out-of-the-box image quality with 1.9mm pixel pitch and pre-calibration
- Easy control and configuration via Control Q app for mobile devices
- Unique quad pixel design with advanced contrast boosting for darker black levels and brighter whites
- Calibre HQUltra 4K image processing technology delivers lightning-fast switching and sharp scaling
- OSD provides easy access to display settings and functions directly with a remote.
Experience stunning, larger-than-life visuals with the 163-inch Optoma FHDQ163 QUADZilla Direct View LED display. Employing a unique packaging process, the all-in-one LED display easily installs in three steps, bringing a beautiful large format display in hours, not days.
Image optimizations ensure every FHDQ163 is ready to impress with richer colors, brighter whites, and deeper black levels without a time-consuming calibration process - every display is pre-calibrated. Calibre HQUltra image processing technology provides 4k source compatibility and lightning-fast input switching that makes all video sources and input resolutions look their best.
Wide Viewing Angle
Optoma QUAD range supports a wide viewing angle of 170 degrees allowing for image retention across a range of viewing locations.
Size and Assembly
With a simple three step process, the complexity of a traditional LED build and installation is removed. Simply connect the display sections, mount the display and apply LED tiles to the connecting area. With this unique pre-build process, installation time required is dramatically reduced from days to hours.
Wireless Content Sharing
Speed up meetings by seamlessly connecting devices with the Optoma TapCast Pro app. The FHDQ163 enables wireless content sharing for up to 4 devices simultaneously at the tap of a button. Enable BYOD, connect with any Windows / Android / iOS and Chromebook device so you can focus on the content while the screen does the rest.
Quad Pixel Technology
A unique 4-in-1 SMD layout that sees SMDs grouped in fours under one surface, allowing for a smoother screen surface, wide viewing angle, and a more robust design.
Scaling and Switching
Optoma LED displays use industry leading Calibre HQUltra 4K image processing technology which provides best in class picture quality with low latency video processing. Inputs can be switched seamlessly in as little as 0.25 seconds. The same processor can directly drive loudspeakers in meeting rooms and smaller conference rooms, plus line level balanced stereo outputs to drive an external amplifier or powered loudspeakers.
Fully optimized LED display
Optoma QUAD range comes pre-calibrated out-of-the-box, removing the hassle of managing software and the various associated files, whilst ensuring the image is optimized for use straight away. Integrated HQUltra and media player technology eliminates the need for any additional separate devices associated with traditional LED solutions.
Eco Friendly
Supporting <0.5W in standby mode, that conforms with ErP regulations and the ability to manage the display from a central control system, power consumption is reduced which saves on energy costs.
Advanced contrast
Boasting a unique QUAD pixel design, contrast levels are improved allowing for darker blacks and brighter whites.
Single Power Cable
Simplify installation with a single power cable. The 240V power cable delivers the necessary voltage and wattage to reliably drive the FHDQ163, unlike some solutions that require two power cables.
Ambient Light Sensor
An integrated ambient light sensor enables automatic brightness adjustments depending on available light. The dynamic brightness ensures the display is always at optimal brightness for visibility and eye comfort.
In The Box
- FHDQ163 display
- Remote
- USB Wi-Fi adapter
- Tile removal tool
- Spare LED tiles
- Wall mount
- Flight case
- 2x removable grip handles
Manuals/Guides
Manufacturer Specs
Model: FHDQ163 Specifications | |
Description | QUADZilla 163" all-in-one QUAD LED display |
TECHNICAL SPECIFICATIONS | |
Brightness | 600 nits (calibrated) |
Brightness Control Levels | 1 to 100% steps |
Contrast Ratio | 5,000:1 |
Frame Color | Black |
Ingress Protection | IP40 (front), IP20 (back) |
LED Tiles | Front access |
Lifespan | >100,000 hrs |
Maximum Input Resolution | 4K UHD (3840 x 2160) @ 60Hz |
Minimum Viewing Distance | 6.23’ |
Native Resolution | 1080p Full HD (1920 x 1080) |
Screen Size | 163″ (diagonal), 141.73″ x 79.72″ (WxH) |
View Angle |
