Product Details
Samsung PH49F-P. Product design: Digital signage flat panel. Display diagonal: 124.5 cm (49"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 700 cd/m², HD type: Full HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Tizen 2.4. Product colour: Black
The all-new embedded media player powered by TIZEN
The new 2016 SMART Signage that supports SSSP 4.0 allows for a stronger, faster and more stable performance than its previous models. Transcending past hardware performance, the new SSSP 4.0 enables CMS partners to develop and deploy advanced web applications which can help to effectively manage content and SMART Signage for their customers.
Offering robust options for content creation, scheduling and deployment tools
A key aspect of the enhanced TIZEN-based SSSP 4.0 platform, Samsung’s MagicInfo Player S4 enables users to fully leverage the power of their display network from any location through a centralized server. More useable than ever, MagicInfo Player S4 merges a dedicated Backup Player with DataLink content streaming capabilities to reduce the effort needed to share vital information.
Bring an end to unwanted glare and always be assured of high visibility and readability
Equipped with a non-glare frontal panel, the PHF and PMF Series displays reduce natural and ambient light interference to ensure continuous readability in any location. Image visibility and information readability are deemed to be very high, because it is less reflective under light or sunlight, which poses no issues when used with QSR menu boards, or airport flight schedule boards with ample natural light.
Unlock easier and more flexible control due to a centralized infrared receiver
The standalone displays’ integrated centralized infrared receiver (IR) ensures easier and more flexible user control. All models can receive the IR signal on individual panels via Central IR. Through tailored installation or mounting, users can navigate the IR functionality from various locations, further augmenting uninterrupted performance.
Put your worries to rest knowing that your display is protected from a range of environmental conditions
All of Samsung’s new PMF and PHF standalone displays are IP5x certified, signifying their dust-resistant design and ability to withstand a range of environmental conditions. The certification alleviates concerns about dust accumulating on displays installed on subway trains or on external platforms. Customers can conveniently use this IP5x certified display without needing to prepare additional enclosure in dusty places. Uninterrupted, 24/7 content delivery is always assured regardless of surrounding natural or interactive conditions.
Increase content possibilities with Samsung PIMs
PHF-P series are designed to use content from various external sources including Samsung PIMs. Samsung PIMs use Intel Open Pluggable Specification (OPS) connectivity to enable power and video source delivery through a single cable. No additional power cord is necessary.
Specifications
| General | |
|---|---|
| Brand | Samsung |
| Manufacturer part number | PH49F-P |
| HSSL part number | HS-SAM-PH49F-P |
| Product type | Signage Displays |
| Display | |
| LED backlighting type | Edge-LED BLU |
| Display diagonal | 124.5 cm (49") |
| Display technology | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 700 cd/m² |
| HD type | Full HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 4000:1 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.56 x 0.56 mm |
| Active display area (W x H) | 1073.779 x 604 mm |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
| Colour gamut | 72% |
| Ports & interfaces | |
| HDMI ports quantity | 2 |
| HDMI version | 2.0 |
| DVI port | Yes |
| DVI-I ports quantity | 1 |
| VGA (D-Sub) input ports | 1 |
| DisplayPorts quantity | 2 |
| DisplayPort version | 1.2 |
| USB port | Yes |
| USB ports quantity | 2 |
| USB version | 2.0 |
| Ethernet LAN (RJ-45) ports | 1 |
| Audio (L/R) in | 1 |
| Audio (L/R) out | 1 |
| RS-232C | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 20 W |
| Design | |
| Product design | Digital signage flat panel |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 400 x 400 mm |
| Bezel width (bottom) | 6.9 mm |
| Bezel width (side) | 8.9 mm |
| Bezel width (top) | 6.9 mm |
| Performance | |
| On Screen Display (OSD) | Yes |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| International Protection (IP) code | IPX5 |
| Power | |
| Power consumption (typical) | 115 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Heat dissipation | 562.65 BTU/h |
| Computer system | |
| Computer system | Yes |
| Processor family | ARM Cortex |
| Processor model | A12 |
| Processor frequency | 1.3 GHz |
| Processor cores | 4 |
| Internal memory | 2.5 GB |
| Internal storage capacity | 8 GB |
| Operating system installed | Tizen 2.4 |
| Weight & dimensions | |
| Width | 1092.6 mm |
| Depth | 29.9 mm |
| Height | 624.8 mm |
| Weight | 13.2 kg |
| Packaging content | |
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC |
| Warranty card | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Other features | |
| L2 cache | 1000 KB |
| Memory clock speed | 1300 MHz |
| Quick start guide | Yes |
| Plug and Play | Yes |
Specifications are supplied by the manufacturer via Open Icecat and may change without notice. HSSL part number HS-SAM-PH49F-P.
