Product Description
Shuttle XPC X50V7 Black Barebone System - All-in-One - 1 x Processor Support - Intel Celeron 8th Gen 4205U Dual-core (2 Core) - Intel Chip - 15.6" Active Matrix TFT LCD Touchscreen 1366 x 768 Display - 64 GB DDR4 SDRAM DDR4-2133/PC4-17000 Maximum RAM Support - 2 Total Memory Slots - Serial ATA/600 Controller - Intel UHD Graphics 610 Graphic(s) - 1 2.5" Bay(s) - HDMI - 1 SATA Interface(s) - Gigabit Ethernet - 4 USB 3.2 Gen 1 Port(s) - 65 W
All-in-One PC for POS, POI, Kiosk Applications
The Shuttle XPC all-in-one X50V7 is the latest addition to the X50 Series and is powered by Intel's Celeron 4205U processor. The new Whiskey Lake-U processor architecture helps improve on power consumption and computing power. Thanks to its passive cooling, the system is virtually noiseless, maintenance-free and approved for 24/7 nonstop operation. Particularly suitable for vertical applications is the arrangement of connectors at the bottom and the IP54 compliant front panel which is dust-protected and protected from splashing of water.
Features
- With Serial ATA/600 interface get superb reliability and high-speed data transfer
- DDR4 SDRAM compatible slot - Install memory that synchronizes electrical and clock signals for an efficient data throughput
- Featuring Gigabit Ethernet port for ultra-fast network speeds
- Connect USB-enabled devices via 7 USB ports
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type Barebone System
Input Voltage 120 V AC
Input Voltage 230 V AC
Maximum Memory Supported 64 GB
Screen Resolution 1366 x 768
Weight (Approximate) 7.94 lb
Form Factor All-in-One
Manufacturer Shuttle, Inc
Product Model X50V7 Black
Product Name XPC All-in-One Barebone X50V7 Black
Processor Type Celeron
Product Line XPC
Screen Size 15.6"
Controller Type Serial ATA/600
Brand Name Shuttle
Operating System Supported Windows 10 x64
Operating System Supported Linux
Memory Technology DDR4 SDRAM
Processor Model 4205U
Memory Standard DDR4-2133/PC4-17000
Height 12.9"
Width 15.4"
Depth 1.7"
Processor Core Dual-core (2 Core)
Touchscreen Yes
64-bit Processing Yes
Processor Manufacturer Intel
Chipset Manufacturer Intel
Graphics Controller Manufacturer Intel
Graphics Controller Model UHD Graphics 610
Bluetooth Yes
Wireless LAN Yes
Number of SATA Interfaces 1
Number of Internal 2.5" Bays 1
Number of Total Memory Slots 2
Graphics Memory Technology DDR4 SDRAM
Graphics Memory Accessibility Shared
Display Screen Type Active Matrix TFT LCD
Number of Processors Supported 1
Ethernet Technology Gigabit Ethernet
Number of Total Expansion Bays 1
HDMI Yes
Webcam Yes
Maximum Power Supply Wattage 65 W
Total Number of USB Ports 7
Number of Onboard USB 2.0 Ports 1
Processor Generation 8th Gen
Energy Star Yes
Product Color Black
Number of USB 3.2 Gen 1 Ports 4
Note Images may not be exact, please check specifications.
