Product Details
The ThinkSystem 18.5" LCD Console is a flat-panel console that offer a convenient way to manage space-constrained rack environments from a single console. This densely packed 1U solution let you easily set up and control rack-mounted servers. It offers additional space savings by allowing the mounting of a KVM switch in the space behind the console. The console includes an 18.5-inch LCD display and US English keyboard, and is based on the Vertiv CLRA Local Rack Access Console, model CLRA19KMM.
The ThinkSystem 18.5" LCD Console is shown in the following figure.
Features
The features of the ThinkSystem 18.5" LCD Console include:
- Integrated 18.5-inch high-resolution display supports selectable display methods and resolutions
- The flat-panel display extends well above the keyboard and offers an easy viewing angle
- Installs in a rack and consumes only 1U of rack space
- Supports the mounting of a KVM switch behind the console to save space
- Tool-less installation for ease of use and installation in minutes
- Includes slides and integrated cable-management arm so the unit can close and slide back into the rack
- Provides easy local access and control of a server
- Compatible with Console Managers for control and access of multiple servers
- Testing to ensure easy integration into Lenovo rack solutions
- A complete, ready-to-install package
- Able to be shipped installed in the rack
- Includes a cable-management arm (CMA)
- Includes a USB-attached 100-key US English keyboard with touchpad pointing device and number keypad
- Includes two passthrough USB 2.0 ports accessible from the front, for the use of optical media, secure access keys, or other USB devices
Technical specifications
The following table lists the specifications of the ThinkSystem 18.5" LCD Console.
| Feature | Value |
|---|---|
| Display | |
| Display type | 18.5" LCD display, 16:9 aspect ratio |
| Display resolution | 1920 x 1080, 60Hz maximum resolution 1366 x 768, 60Hz standard resolution 800 x 600, 60Hz minimum resolution |
| Scaling choices | Full Screen, Aspect, 1:1 |
| Connector | VGA |
| Display active area | 410 mm x 230 mm |
| Diagonal viewable image | 18.5 inches |
| Pixel pitch | 300 x 300 |
| Viewing angle | 160° Horizontal (typical) 150° Vertical (typical) |
| Luminance | 250 cd/m2 |
| Keyboard and mouse | |
| Keyboard | Full size 100 keyboard with number keypad |
| Pointing device | Integrated touchpad |
| Connector | USB |
| USB ports | |
| Ports | 2x USB 2.0 ports, passthrough |
| Power source | |
| Power | 22W maximum, 17W nominal, <1W standby |
| Power supply input | 110-240 Vac auto-ranging |
| Power connector | IEC C14 |
Supported servers
The ThinkSystem 18.5" LCD Console can be used with a server or KVM console switch with VGA and USB local console ports.
Warranty options
The ThinkSystem 18.5" LCD Console has a 3 year warranty. When ordered as a feature code as part of a supported Lenovo rack cabinet, the console assumes the rack cabinet’s base warranty and any warranty upgrades.
Physical specifications
The ThinkSystem 18.5" LCD Console has the following physical specifications.
- Height (rack units): 1U
- Dimensions (console only): 481mm x 526mm x 43mm
- Weight (console only): 8.3kg
- Supported rack post distances (measured outside-to-outside):
- Console only: 620mm - 920mm
- Including space for KVM switch: 730mm - 920mm
Operating environment
The ThinkSystem 18.5" LCD Console is supported in the following environment:
- Temperature
- 0°C - 50°C, operation
- -20°C - 60°C, storage
- Humidity
- 10% - 80%, operation
- 5% - 95%, storage
- Altitude
- 0m to 3000m, operation
- -15m to 10,000m, storage
