Product Description
Advantech 8G + 2G Combo Managed POE+ switch w/Wide temp - EKI-7710G-2CPI-AU
The EKI-7710G series support Network Management System, eight Gigabit Power over Ethernet (PoE) and two Gigabit combo ports. It provides up to 30 watts per port to fulfill the Power Device. It’s embedded with IXM function, providing fast deployment and saving time and costs.
- 8 x IEEE 802.3 af/at PoE Gigabit ports + 2 x Gigabit copper/SFP combo ports
- SFP socket for easy and flexible fiber expansion
- Redundancy: X-Ring Pro (ultra-high-speed recovery time,
- IXM function enables fast deployment
- Security: 802.1x (port-based, MD5/TLS/TTLS/PEAP encryption), RADIUS
- Management: SNMP v1/v2c/v3, WEB, Telnet, standard MIB, private MIB
- NEMA TS2 for traffic control
- EN50121-4 approval for railway trackside deployment
- Dual 24 ~ 48 VDC power input and 1 x relay output
- Wide operating temperature range of -40 ~ 75°C (EKI-7710G-2CPI)
Other Details
(Manufacturer Standard Warranty) - Not Clear what product you need, or can't find your specific product/service part number? Call us +1 888 988 5472 | Fax: +1 888 920 3445. You can also use the quote request pageProduct Videos
Custom Field
Product Type Ethernet Switch
Input Voltage 24 V DC
Input Voltage 48 V DC
Manufacturer Part Number EKI-7710G-2CPI-AU
Power Source DC
Power Source PoE+
Limited Warranty 5 Year
Layer Supported 2
Weight (Approximate) 2.65 lb
Features IP30
Form Factor DIN Rail Mountable
Form Factor Wall Mountable
Manufacturer Advantech Co., Ltd
Product Model EKI-7710G-2CPI
Product Name EKI-7710G-2CPI Ethernet Switch
Network Technology 10/100/1000Base-T
Network Technology 1000Base-X
Power Consumption 12.10 W
Product Series EKI-7710G
Brand Name Advantech
Plug/Connector Type Terminal Block
Expansion Slot Type SFP
Country of Origin Taiwan
Height 6"
Width 2.9"
Depth 4.1"
Manageable Yes
Maximum Data Transfer Rate 125 MB/s
Ethernet Technology Gigabit Ethernet
Network (RJ-45) Yes
Number of SFP Slots 2
Modular Yes
Media Type Supported Twisted Pair
Media Type Supported Optical Fiber
Total Number of Network Ports 8
PoE (RJ-45) Port Yes
Port/Expansion Slot Details 8 x 10/100/1000BASE-T Gigabit Ethernet PoE+ Network Port
Port/Expansion Slot Details 2 x Gigabit Ethernet TP/SFP Combo Port
Total Number of Expansion Slots 2
Networking Standards IEEE 802.1p
Networking Standards IEEE 802.3ad
Networking Standards IEEE 802.1x
Networking Standards IEEE 802.1D
Networking Standards IEEE 802.1s
Networking Standards IEEE 802.1w
Networking Standards IEEE 802.3at
Networking Standards IEEE 802.3af
Product Material Metal
Environmental Compliance Restriction of Hazardous Substances (RoHS)
Note Images may not be exact, please check specifications.
Required A Volume Purchase Contact us for a volume pricing | volumeorders@hssl.us
