Product Description
8 Megapixel IP Plug & Play Outdoor Bullet with 4 Fixed Lenses, WDR, 65’ IR Range, SD Card Slot, PoE/DC12V
Core Features:
- 8 Megapixel (4096 x 1800) Resolution
- InVid-Starlight 180° Panoramic Camera with 4 Lens
- True AI Human and Vehicle Classification for Line Crossing and Intrusion Detection
- H.265/H.264/MJPEG Compression
- True WDR 120dB
- Smart IR up to 65’
- SD Card Local Storage, 256GB
- Audio Input/Output
- IK10 Vandal Resistant
- IP67 Weather Resistant
- 12VDC/PoE Operation
- ONVIF
- Free MAC client software available to manage your system from your Apple computer
- Free Central Management Software (CMS) to manage multiple units & sites from a single platform
- Free iOS & Android Apps for Smart Phones & Tablets
Weight | 4.6 lbs |
---|---|
Dimensions | 12 × 12 × 10 in |
Brand | InVid |
IP Camera Audio Input | Audio Input |
IP Camera Audio Output | Audio Output |
IP Camera Type | Bullet |
IP Camera Housing Material | Metal |
IP Camera IR Range | 51-100 ft |
IP Camera Lens | Fixed |
IP Camera Light Options | IR, Starlight |
IP Camera Megapixels | 8 MP |
IP Camera Weather Rating | IP67 Weatherproof |
Specialty Camera Features | True Human Body + Vehicle Detection |
Camera PAR-P8PANMULTI-AI
Image Sensor Four 1 / 2.8 “ Progressive Scan CMOS
Max. Resolution 4096 × 1800
Electronic Shutter 1 s ~ 1 / 10000 s; auto/manual
Day & Night IR-CUT
S/N Ratio >50dB
NR 2D/3D DNR
Gain Control Manual/auto
White Balance Manual/auto/indoor/outdoor
HLC Yes
Lens 3.3mm
Lens Mount M12
Wide Dynamic Range 120dB
Field of View Pan: ≥180°; Tilt: 80°
Min. Illumination
Color: 0.03Lux
B&W: 0.001Lux
0 Lux with IR
IR Distance 65’
IR LEDs Eight
Smart IR Yes
Image & Encoding
Video Compression H.265 / H.264 / MJPEG
Video Bit Rate 128 Kbps ~ 16 Mbps
Audio Compression G.711A/U
Resolution 4096 × 1800, 3480× 1680 ), 2880 × 1264, 1024 × 452, 704 ×
320
Image Settings ROI, Saturation, Brightness, Chroma, Contrast, NR, etc.
adjustable through client software or web browser
ROI Each ROI to be configured separately
Smart Features
Basic Event Motion detection, video tempering detection, SD card
error, IP conflict, cable disconnection
Smart Event
Object removal detection, regional intrusion detection,
abnormal video detection, line crossing detection, people
intrusion, people counting (optional)
Alarm Linkage SD card record, triggering record, notifying control center,
uploading SD card, sending E-mail
Network
Protocols
HTTP, HTTPs, IPv4/IPv6, 802.1x, QoS, FTP, SMTP, UPnP, SNMP,
DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP,
PPPoE, DHCP
API ONVIF, API, SDK
Simultaneous Live View Up to 10 channels
User/Host Up to 10 accounts; 3 levels: administrator, advanced user,
normal user
Security Measures
User authentication; host authentication (MAC address);
HTTPs encryption; IEEE802.1x port-based network access
control; IP address filtering
Interfaces
Storage Built-in micro SD card slot, up to 128GB
Audio 1CH audio input; 1CH audio output
Network 1 RJ 45 10M/100M Ethernet port, PoE (802.3af)
RS 485 1 CH; Pelco-D/P protocol, custom protocols available
Alarm 1CH alarm input; 1CH alarm output
General
Power DC12V/PoE(802.3af)
Working Environment Temperature: -22°F ~ 140°F (-30°C~60°C) Humidity: <95%
(non-condensing)
Protection Grade IP 67, IK 10, TVS6000V lightning protection, surge protection
and voltage transient protection
Weight Approx. 4.6 lbs (2.1KG) (net); Approx. 8 lbs (3.61KG) (gross)
