Product Details
Key Applications- High Performance Computing
- AI/Deep Learning Training
- Media/Video Streaming
- Industrial Automation, Retail
- Cloud Gaming
Key Features
- Single Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processor
- Intel® C621A Chipset
- 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs
- 3 PCI-E Gen 4.0 x16 FHFL DW
- 2 front Hot-swap 2.5" U.2 NVMe Gen4 drive bays
2 M.2 NVMe and SATA for boot drive only - 2600W Redundant (1+1) Power Supplies Titanium Level (96%) (Full redundancy based on configuration and application load)
- AST2500 BMC
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Parts List - (Items Included) | |||
| |
Part Number |
Qty |
Description |
| Motherboard / Chassis | MBD-X12SPG-NF |
2 |
Super X12SPG-NF Motherboard |
| Cable 1 | CBL-CDAT-1056 | 1 | 2x5,PH2.54 to 2x5,PH2.54,7cm,28AWG,RoHS |
| Cable 2 | CBL-PWCD-0376-IS | 2 | PWCD,US,IEC60320 C19 TO C20,940mm (3ft),14AWG,15A,250V,Black |
| Cable 3 | CBL-PWEX-1093-36 | 2 | MicroFit,2x2, P3.0,F to MicroFit,2x2,P3.0,F,36CM,10A/pin |
| Cable 4 | CBL-PWEX-1148-20 | 2 | MicroHi,2x4,PH3. to 2x4,PH4.2,MiniFit,20CM,8.5A/p,18AWG, |
| Cable 5 | CBL-PWEX-1148-50 | 4 | MicroHi,2x4,PH3. to 2x4,PH4.2,MiniFit,50CM,8.5A/p,18AWG, |
| Cable 6 | CBL-PWEX-1257 | 1 | 2x4,PH3.0 to 2x4,PH3.0,7CM,4A,22AWG,RoHS |
| Cable 7 | CBL-SAST-1235-85 | 2 | Slimline x8 (STR) to Slimline x8 (STR),INT,35CM,85 OHM |
| Fan Holder | MCP-220-82620-0N | 2 | Dual 2.5 NVMe4 Drive Kit for 216B/826B/417B/846X/847B,RoHS |
| Air Shroud | MCP-310-22711-0B | 2 | Mylar air shroud sets X12SPG-NF for SC227G(3x GPU) |
| Riser Card | RSC-GB-6G4 | 2 | 1U Rear LHS GPU riser card withonePCI-E4.0X16 slot,HF,Ro |
| Riser Card | RSC-GF-6G4 | 4 | 1U Front LHS GPU Riser card with onePCI-E4.0x16slot,HF,R |
| Storage Controller Card | SCC-P2N2FG-P1A-A | 1 | PDB with 2x NVMe, paired with SCC-P2N2FG-P1A-B |
| Storage Controller Card | SCC-P2N2FG-P1A-B | 1 | PDB with 2x NVMe, paired with SCC-P2N2FG-P1A-A |
| Software | SFT-OOB-LIC | 2 | License key for enabling OOB BIOS management |
| Heatsink / Retention | SNK-P0077V | 2 | X12 ICX/CPX CPU Heatsink (78x113x25.5mm), VC Base, Cu Fin |
| *Power Supply | PWS-2K63A-1R | 2 | 1U 2600Wredundant single outpupowersupply with wide range in |
| *Cable 8 | CBL-PWEX-1251 | 2 | [NR] FAN,2x4 to 2x 1x4 and 1x4,5A/pin,42.5CM,22/24AWG |
| *Cable 9 | CBL-PWEX-1252 | 2 | [NR] FAN,2x4 to 2x 1x4 and 1x4,5A/pin,58CM,22/24AWG |
| *FAN 1 | FAN-0219L4 | 4 | 80x80x80 mm, 14.2K-15K RPM Counter-rotating, Hot-swappable F |
| *Front Panel | FPB-FP827BR | 1 | 2U BigTwin front control board - right side |
| *Rail Set | MCP-290-00144-0N | 1 | 2U fixed rail set, quick release, default for 2,3U 17.6"W |
| *Front Panel | FPB-FP827BR | 1 | 2U BigTwin front control board - right side |
| *Rail Set | MCP-290-00145-0N | 1 | Left fixed rail (quick) for 2U 17.6";W chassis |
| *Rail Set | MCP-290-00146-0N | 1 | Right fixed rail (quick) for 2U 17.6";W chassis |
